Chapter 2: Jumpers and Connectors
FAN Connectors
Connector type: 1x4 4-pin Wafer
Connector location: J5 and J6
Pin
1
2
3
4
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
RTC Battery IN Connector
Connector type: 1x2 JST, 2-pin header
Connector location: J7
Definition
GND
+12V
FAN_TAC
FAN_CTL
21
Pin
1
2
RTC battery IN
Definition
GND
NEX 605 User Manual
