Chapter 2: Jumpers and Connectors

USB8/9 Connector

Connector type: 2x5 10-pin header
Connector location: J3
Pin Definition
1 5VDUAL
3 DATA8_N
5 DATA8_P
7 GND
9 NC
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
Pin Definition
2 5VDUAL
4 DATA9_N
6 DATA9_P
8 GND
10 NC

LVDS Backlight Connector

Connector type: 1x7 JST, 7-pin header
Connector location: J4
Pin Definition
1 +5V
3 Backlight power(+12V)
5 GND
7 Backlight enable
18
Pin Definition
2 Backlight power(+12V)
4 Backlight brightness control
6 GND
