Chapter 2: Jumpers and Connectors
COM4 Connector (RS232)
Connector type: 1x10 10-pin header
Connector location: J9
Pin
Definition
1
DCD4
3
TXD4
5
GND
7
RTS4
9
RI4
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
Pin
Definition
2
RXD4
4
DTR4
6
DSR4
8
CTS4
10
GND
IR Connector
Connector type: 1x5 5-pin header
Connector location: JP8
Pin
1
2
3
4
5
20
Definition
+5V
NC
IRRX
GND
IRTX
NEX 605 User Manual
