Minicom Smart IP Access User Manual page 9

4. Connect Smart IP Access to the network by attaching one of the LAN ports to
an Ethernet port on your Network. IP Access has two LAN interfaces – see
Initial Settings
5. Connect to the power supply using the power cord provided.
Figure 4 and Figure 5 illustrate the connections to a computer and KVM switch
respectively, with the optional KVM console.
LAN / WAN
A u t o 1 2
h p 1 9 2 5
www.minicom .com
1 1
S
E
L
R
A
I
N A
L
2 2
POWER
100-240 VAC 50/60 Hz
Figure 4 Smart IP Access connections to a computer
USER GUIDE
3 in 1 CPU cable
CONSOLE COMPUTER
User over IP
8
Target PC
