a. Power consumption
Vin = 12Vdc
Idle mode
Standby mode
Average In-Use :
2Mbps@10dBm Tx
7.2Mbps Rx
384Kbps@10dBm Tx
GSM CSD (9600bps)
GPRS PSD
EDGE
b. RF bands
GSM850 :
Tx = 824MHz - 849MHz,
EGSM900 :
Tx = 880MHz - 915MHz,
DCS1800 :
Tx = 1710MHz - 1785MHz,
PCS1900 :
Tx = 1850MHz - 1910MHz,
UMTS2100 :
Tx = 1920MHz - 1980MHz,
UMTS1900 :
Tx = 1850MHz - 1910MHz,
UMTS900 :
Tx = 880MHz - 915MHz,
UMTS850 :
Tx = 824MHz - 849MHz,
c. Receive sensitivity
Band
GSM850 (2% ber) CS
EGSM900 (2% ber) CS
DCS1800 (2% ber) CS
PCS1900 (2% ber) CS
UMTS2100(.1% ber) 12.2Kbps
UMTS1900(.1% ber) 12.2Kbps
UMTS900(.1% ber) 12.2Kbps
UMTS850(.1% ber) 12.2Kbps
Notes :
-
Ber : bit error rate
-
CS : Circuit-switched
HSDPA/WCDMA
31mA
105mA
158mA HSUPA
158mA HSDPA
137mA WCDMA
-
-
-
Typical Rx Sensitivity
(dBm)
-107.5
-107.5
-106.5
-106.5
-110.5
-110.5
-110.5
-111.5
Intercel Pty. Ltd.
A.C.N. 007 077 161
33 Glenvale Crescent
Mulgrave VIC. Australia 3170
Email :
intercel@intercel.com.au
Internet :
www.intercel.com.au
Ph : 61 3 9239 2000 Fax : 61 3 9561 2614
GSM/GPRS/EDGE
31mA
80mA
-
-
-
87mA
110mA
137mA
Rx = 869MHz - 894MHz
Rx = 925MHz - 960MHz
Rx = 1805MHz - 1880MHz
Rx = 1930MHz - 1990MHz
Rx = 2110MHz - 2170MHz
Rx = 1930MHz - 1990MHz
Rx = 925MHz - 960MHz
Rx = 869MHz - 894MHz
Maximum Rx Sensitivity
(dBm)
-106
-106
-105
-105
-109
-109
-109
-110
