Smart SAM2S User Guide V1.4

7 Electrical Characteristics

7.1 Power Consumption

Network search
Idle mode
Connected mode
GPRS PSD transfer
Peak current during the 577µs transmission pulse

7.2 RF Bands

EGSM900 : Tx = 880MHz - 915MHz,
DCS1800 : Tx = 1710MHz - 1785MHz,

7.3 Receive Sensitivity

Band
EGSM900 (2% ber) CS
DCS1800 (2% ber) CS
Note:
- Bit error rate < 2.4%

7.4 Conducted Transmit Power

Parameter Min
GSM900 +31dBm
DCS1800 +28dBm
11
Rx = 925MHz - 960MHz
Rx = 1805MHz - 1880MHz
Typical Rx Sensitivity
(dBm)
-102
-102
Typical Max
+33dBm +35dBm
+30dBm +32dBm
70mA @ 12V
45mA @ 12Vdc
95mA @ 12Vdc
250mA @ 12Vdc
1.2A @ 12V
Maximum Rx Sensitivity
(dBm)
-107
-107
Ver1.4
