7 Electrical Characters

7.1 Power Consumption

Idle mode
Average in-use mode
Full Tx power
Peak current requirement

7.2 Receive Sensitivity

Measurement setup:
(LTE) CAT M1 Throughput >95% According to 3GPP 36.521-1
(LTE) CAT NB1 Throughput >95% According to 3GPP 36.521-1
MODE/BAND
CAT M1 / Band 3
CAT M1 / Band 5
CAT M1 / Band 8
CAT M1 / Band 28
CAT NB1 / Band 3
CAT NB1 / Band 5
CAT NB1 / Band 8
CAT NB1 / Band 28
30mA @12V
80mA@12V
90mA@12V
0.3A@12V
REF Sensitivity (dBm)
-108 dBm
-108.8 dBm
-108.4 dBm
-108 dBm
-115.6 dBm
-114.6 dBm
-113.8 dBm
-115.2 dBm
SAMXT User Guide V1.5
3GPP REFSens (dBm)
-99.3 dBm
-100.8 dBm
-99.8 dBm
-100.8 dBm
-107.5 dBm
-107.5 dBm
-107.5 dBm
-107.5 dBm
