7 Electrical Characteristics

7.1 Power Consumption

Vin = 12Vdc
Idle mode
Standby mode
Average In-Use:
2Mbps@10dBm Tx
7.2Mbps Rx
384Kbps@10dBm Tx
GSM CSD (9600bps)
GPRS PSD
EDGE

7.2 RF Bands

GSM850 : Tx = 824MHz - 849MHz,
EGSM900 : Tx = 880MHz - 915MHz,
DCS1800 : Tx = 1710MHz - 1785MHz,
PCS1900 : Tx = 1850MHz - 1910MHz,
UMTS2100 : Tx = 1920MHz - 1980MHz,
UMTS1900 : Tx = 1850MHz - 1910MHz,
UMTS900 : Tx = 880MHz - 915MHz,
UMTS850 : Tx = 824MHz - 849MHz,

7.3 Receive Sensitivity

Band
GSM850 (2% ber) CS
EGSM900 (2% ber) CS
DCS1800 (2% ber) CS
PCS1900 (2% ber) CS
UMTS2100(.1% ber) 12.2Kbps
UMTS1900(.1% ber) 12.2Kbps
UMTS900(.1% ber) 12.2Kbps
UMTS850(.1% ber) 12.2Kbps
Notes :
- BER : bit error rate
- CS : Circuit-switched
12
HSDPA/WCDMA
31mA
105mA
158mA HSUPA
158mA HSDPA
137mA WCDMA
-
-
-
Typical Rx Sensitivity
(dBm)
-107.5
-107.5
-106.5
-106.5
-110.5
-110.5
-110.5
-111.5
GSM/GPRS/EDGE
31mA
80mA
-
-
-
87mA
110mA
137mA
Rx = 869MHz - 894MHz
Rx = 925MHz - 960MHz
Rx = 1805MHz - 1880MHz
Rx = 1930MHz - 1990MHz
Rx = 2110MHz - 2170MHz
Rx = 1930MHz - 1990MHz
Rx = 925MHz - 960MHz
Rx = 869MHz - 894MHz
Maximum Rx Sensitivity
(dBm)
-106
-106
-105
-105
-109
-109
-109
-110
