Intercel SAM3G+ User Manual page 3

1. Introduction
The SAM3G+ is a compact, light-weight, UMTS, HSPA based modem. It provides GSM, GPRS,
EDGE and WCDMA connectivity. The SAM3G+ is a quad-band GSM/GPRS/EDGE 850MHz,
900MHz, 1800MHz, 1900MHz and a quad-band WCDMA/HSDPA : 850MHz, 900MHz,1900MHz,
2100MHz
The SAM3G+ is designed for both mobile and fixed M2M applications. It has an RJ45 socket for
both input voltage and serial RS232 signals, a MiniB USB connector, a SMB-Jack for antenna
connection, a SIM holder and an LED indicator.
The SAM3G+ is capable of sending/receiving SMS, Circuit switched data and Packet-switched
data.
SIM holder
LED indicator
Mini USB connector
Type Approval
Mobile station modem Version
TA code
EU approval
RJ45 for input power and serial RS232
GCF full type approval
Qualcomm's MSM6290
35362602
CE-0682
Intercel Pty. Ltd. A.C.N. 007 077 161
33 Glenvale Crescent
Mulgrave VIC. Australia 3170
Email : intercel@intercel.com.au
Internet : www.intercel.com.au
Ph : 61 3 9239 2000 Fax : 61 3 9561 2614
SMB-Jack antenna
connector
