Smart SAM2W User Guide V1.2

7 Electrical Characteristics

7.1 Power Consumption

Network search
Idle mode
Connected mode
GPRS PSD transfer
Peak current during the 577µs transmission pulse

7.2 RF Bands

Tx = 824MHz – 849MHz
GSM850
EGSM900 Tx = 880MHz - 915MHz,
DCS1800 Tx = 1710MHz - 1785MHz,
PCS1900 Tx = 1850MHz - 1910MHz,

7.3 Receive Sensitivity

Band
GSM850
EGSM900
DCS1800
PCS1900

7.4 Conducted Transmit Power

Parameter
GSM850 & EGSM900
DCS1800 & PSC1900
11
Typical Rx Sensitivity
(dBm)
-109dBm
-109dBm
-108dBm
-108dBm
Min
+5dBm +33dBm
+0dBm +30dBm
65mA @ 12V
40mA @ 12Vdc
90mA @ 12Vdc
245mA @ 12Vdc
500mA @ 12V
Rx = 869MHz – 894MHz
Rx = 925MHz - 960MHz
Rx = 1805MHz - 1880MHz
Rx = 1930MHz - 1990MHz
Max
Ver1.2
