Korg SDD-200 Owner's Manual page 9

REC SYNC SECTION
mo saotlmq
SEE
RECSYNC
6 REC Switch
In the sampling and sequencer modes this is used
as the recording switch. In the trigger overdub mode
it is used to manually set the delay time.
7 TRIG OVERDUB Switch
This switch is used to select the trigger overdub
mode with automatic setting of delay time.
t SEQ Switch
This selects the sequencer mode for recording and
repeated playback of phrases of up to 4368ms.
SAMPLING Switch
This selects the sampling mode which allows re
cording of audio signal inputs and reproduction of
the sampled signal when triggered by a foot switch
or other signal source.
10 TRIG LED
This illuminates when a trigger signal is input to the
rear panel trigger jack during trigger overdub, sampl
ing mode operation.
csync
MIDI
11 MIDI Switch
When this switch is on, its LED lights up and the
SDD-2000 can receive MIDI data.
