MCR41-MCR42 User Manual
Using navigation buttons it is possible to quick & easy navigate through the MCR42 menu:
- SEL/Exit to enter or exit a level
- Arrow up/down to circle on the same level
- To save the modified parameters press and hold the SEL /MENU button (
message "SAVED!".

STATUS MENU

RX1
Group
Modulation bar
(from -42 to 0 dB)
Peak deviation ≥ 56KHz

Quick Menu

From FW version 3.0, pushing "Arrow down/scan" button or "Arrow up/sync"
button, it's possible to enter in a circular menu where you can see the main
parameters of the receiver as frequency, group, channel, Expander, RF level,
squelch and audio level.
By name
By Ch/Gr
9
RX2
Channel
RF bar
(8 steps of 10dBµV,
from 10 to 80 dBµV)
rev.10
Frequency
Squelch Level
) until appears the
Status Screen
TX battery
Level
