Advanced:
Info
In the info menu the following information are displayed:
Info description
Supply voltage measured
Power:
MCR42 dual rx / MCR41
Model:
The serial number composed by 1 letter+7 numbers
Serial:
Frequency range according to the MCR band:
L: 470-678
Range: H: 590-822
N: 470-700
M: 566-798
Version of rear panel:
BPA42-PTT/HPN/BAG
Base:
S1LK 42-SX
SLK 42-IK
SLK 42-PH
Type of power supply
Alim:
FW version
Version:
Bootloader version
BL:
FW:
Application version
App:
DSP version
DSP:
HW rev: Hardware version
Options: For this product the option specific the band (L/H/N/M)
HW:
Top: Indicates if there is mounted a Top Feed and the type
Display 0 if there is an old display / 1 if there is a new display
Number of errors.
If the number of errors is > 0 push SEL button to enter on the Errors list.
Errors:
For each error a brief description and the error code is showed.
For more information, please see the Error List section.
rev.10
Select Advanced menu to access to other advanced
parameters
MCR41-MCR42 User Manual
example
12.0Volt
MCR42 dual rx
S3536539
470-678
BPA42-HPN
Ext
v2.0.5
v.1.0.18
v2.5d
v0.0.55r
21
L
EL2
1
0
12
