1 Introduction

The ADM-XP (XP) is an advanced PCI Mezzanine card (PMC) supporting Xilinx Virtex-II PRO™ (V2PRO)
devices, the latest development in FPGA technology. The XP supports 2VP70, 2VP100 or 2VP125 devices
with two embedded PowerPC processors.
The XP utilises an FPGA PCI bridge developed by Alpha Data supporting 64 bit PCI at up to 66MHz. Future
enhancements will provide compatibility with PCI-X. A high speed multiplexed address and data bus connects
the bridge to the target FPGA.
Memory resources provided on-board include DDR SDRAM, DDR2 SSRAM and flash, all of which are
optimised for direct use by the FPGA using IP and toolkits provided by Xilinx.
Flexible I/O is the key to the ADM-XRC-II series of boards and the XP is compatible with a wide selection of
XRM modules that use the 180 pin Samtec interface.

1.1 Specifications

The ADM-XP supports high performance PCI operation without the need to integrate proprietary cores into the
FPGA.
Physically conformant to IEEE P1386 Common Mezzanine Card standard
High performance PCI and asynchronous local bus
Local bus speeds of up to 80MHz
Four banks of 256K * 32 bits of DDR2 SSRAM – option for 512K * 32 bits
Two banks of 64MB DDR SDRAM – option for 128MB
Two flash devices of 16MB each for bridge and target devices
User clock programmable between 5MHz and 200MHz
User front panel adapter with up to 146 free IO signals
Supports 3.3V PCI or PCIX at 64 bits
On board 125MHz LVPECL oscillator
8 x RocketIO Multi-Gigabit Transceiver Connections (optional) @ 2.5Gb/s
Page 5 of 29
ADM-XP
User Manual
ADM-XR-IIPro User Manual
Version 0.2
