6 Front Panel I/O
The XP supports standard XRM's used on the ADM-XRC-II and ADM-XPL cards and also has an additional
connector that brings 7 MGT channels upto the XRM Module site using a differential 28 pin Samtec QSE-DP
series connector to maintain signal integrity.
The XP supports the standard Samtec 180 pin connector but using either with 2.5V or 3.3V signalling which is
globally selected using JP1
JP1 Link Posn
1-2
2-3
6.1
Samtec 180 connector - U8
The table below details the I/O signals that are available on the Samtec 180 connector along with the FPGA
pin that each connects to.
FPGA
Pin
D10
E10
F11
E11
J10
H10
G10
F10
G9
H9
J12
H12
M13
L13
L12
K12
G17
F17
D16
Note 1. Vref1 can be provided by the XRM if required and is applied to banks 0 and 1 in common.
Note 2. TCK, TMS, TDI and TDO are connected to the Coolrunner and not the V2PRO.
Page 15 of 29
VCCIO – Front IO
+3V3
+2V5
Signal
Connector Pins
IO_8N_1
1
IO_8P_1
3
IO_19N_1
5
IO_19P_1
7
IO_6N_1
9
IO_6P_1
11
IO_7N_1
13
IO_7P_1
15
IO_1P_1
17
IO_1N_1
19
IO_25N_1
21
IO_25P_1
23
IO_28N_1
25
IO_28P_1
27
IO_21N_1
29
IO_21P_1
31
IO_49N_1
33
IO_49P_1
35
IO_50P_1
37
+3V3
39
+3V3
41
+3V3
43
+5V
45
+5V
47
Vbatt
49
+12V
51
+12V
53
Presence
55
TCK
57
TMS
59
Signal
2
IO_35N_1
4
IO_35P_1
6
IO_30P_1
8
IO_30N_1
10
IO_58N_1
12
IO_58P_1
14
IO_54N_1
16
IO_54P_1
18
IO_34P_1
20
IO_34N_1
22
IO_2N_1
24
IO_2P_1
26
IO_29P_1
28
IO_29N_1
30
IO_20P_1
32
IO_20N_1
34
IO_26N_1
36
IO_26P_1
38
IO_75P_1
40
IO_75N_1
42
Serial_ID
44
Nc
46
Vref1
48
+2V5
50
+2V5
52
+2V5
54
-12V
56
TDI
58
TRST
60
TDO
ADM-XR-IIPro User Manual
ADM-XP
User Manual
FPGA
Pin
C13
D13
H13
G13
M19
L19
L18
K18
E13
F13
E9
F9
K13
J13
C11
C10
F12
G12
F21
G21
Note 1
Version 0.2
