Alpha Data ADM-XRC-II Pro Hardware Manual page 26

Pin Function UCF name
115 Data[48] +ve User[110]
117 Data[48] -ve User[111]
119 Data[50] +ve User[114]
121 Data[50] -ve User[115]
123 Data[52] +ve User[118]
125 Data[52] -ve User[119]
127 Data[54] +ve User[122]
129 Data[54] -ve User[123]
131 Data[56] +ve User[126]
133 Data[56] -ve User[127]
135 Data[58] +ve User[130]
137 Data[58] -ve User[131]
139 Data[60] +ve User[134]
141 Data[60] -ve User[135]
143 Data[62] +ve User[138]
145 Data[62] -ve User[139]
147 Single 8 User[144]
149 Single 9 User[145]
151 +5V fused
1) Data[] signals can be used for differential Pairs or single ended signals
2) Clock[] can be used for differential clocks or single ended clock signals
3) XRM I0146 connector – AMP/TYCO 767044-4 152 pin Mictor Receptacle
4) Suggested mating part – AMP/TYCO 1-767007-1 152 pin Mictor Plug or similar
5) When using the Virtex II Pro DCI these pins are not available for IO
Page 26 of 29
Tem VII Pro Pin
Res Pin
R65 C32 116
- C33 118
R68 120
H34(5)
- G34(5) 122
R71 D33 124
- E33 126
R73 C24 128
- D24 130
R77 F30 132
- E30 134
R79 L31 136
- K31 138
R81 G26 140
- F26 142
R84 F32 144
- E32 146
N/a F28 148
N/a L27 150
152
Notes
Function UCF name
Data[49] +ve User[112]
Data[49] -ve User[113]
Data[51] +ve User[116]
Data[51] -ve User[117]
Data[53] +ve User[120]
Data[53] -ve User[121]
Data[55] +ve User[124]
Data[55] -ve User[125]
Data[57] +ve User[128]
Data[57] -ve User[129]
Data[59] +ve User[132]
Data[59] -ve User[133]
Data[61] +ve User[136]
Data[61] -ve User[137]
Data[63] +ve User[140]
Data[63] -ve User[141]
Clock[3] +ve User[142]
Clock[3] -ve User[143]
+5V fused
