6.2.3

Polling reception

No operator intervention is required during polling reception.
The printer (printer PP-510, optionally available) prints the status of polling reception
and transmits data in response to polling request as shown below.
TX start frame (time)
POLLING Message - - - Program Unreserved Data Reporting - - -
DNID : 0004 LES ID
Sub Address : 000 Member Number : 001 Response: No Response
Receive Data & Time: 02-02-25 00:01 (UTC)
Start Frame: 00030 Interval: 00030
02-02-25 00:01 (UTC)
Data Report Program has been initiated by Polling.
POLLING Message - - - Initiate Unreserved Data Reporting - - -
DNID :0004 LES ID
Sub Address : 000 Member Number :001 Response: Data Report
Receive Data & Time: 02-02-25 00:01 (UTC)
Start Frame: 00030 Interval: 00030
Data Reported (Poll Response)
LES :Telnor S.S.Inc
DNID :00004
Member No. :001
Position LAT 10:14.03N
LON 124:36.81E
02-02-25 00:06 (UTC)
Successful Data Report Sending.
Data reporting
: 101 (Telnor S.S.Inc)
Received
Polling
TX interval
Command
:101 (Telnor S.S.Inc)
TX data set on Data
Report
Date : 02-02-25
Time : 00:03 (UTC)
Tx message
recipient and
TX data
6. DATA REPORT AND POLLING
Receive Message
Message No. : R0020205.002
Message Ref. No. : 00616923
LES : KDDI
Priority : Normal
Message Size : 121 characters
Receive Data & Time : 02-02-25 04:07 (UTC)
KDD INMARSAT-C SERVICE 25-FEB-02 04:02:28 UTC REF:616923
XXXXXXXXX ABCD X via KDDI LES
D???-12345678-test:test
02-02-25 04:09 (UTC)
Successful Sending message.
Sent Message
DELIVERY CONFIRMATION OFF
Message File : Report
LES : KDDI
Priority : Normal
Destination : TELEX
582+
Date & Time 02-02-25 04:07 (UTC)
Position LAT 12:34.56N
LON 123:45.67E
Course 321.1
Speed 1.1 kn
Received
Polling
Command
Tx message
recipient and
TX data
Message Size: 284 characters
Date : 02-02-25
Time : 04:09 (UTC)
582 (IA5)
Water Temp 32.1
Water Current 22.3 kn
111.0
Depth 123.4FT
