2. OPERATIONAL OVERVIEW
2.2.2

Starting, quitting the application

For information about terminal unit operation see the PC's owner's manual.
1. Turn on the communication unit.
2. Turn on the terminal unit.
3. Double-click the F19PC icon to start the application. After the program
loads the standby display appears.
4. To quit the application, press the F12 key while pressing the Alt key. The
following confirmation window appears. (You may also quit the application by
clicking the Close button at the top right corner of the screen.)
5. [Yes] is selected; press the Enter key.
6. Turn off the terminal unit in accordance with Windows
7. Turn off the communication unit.
Note: If a different method is used to quit the application, any settings changed before
quitting will not be saved.
2.2.3

Key description

Key
Esc
F1 - F10
BackSpace
Insert
Delete
Home
End
Page Up
Page Down
↑, ↓, ←, →
Enter
Shift
Alt
Spacebar
2-4
OK to quit system?
No
Yes Yes
• Cancels key input and returns to previous display screen.
• Long push to return to the standby display.
Select menus. See section 2.2.5.
Deletes the character to the left of the cursor.
Works the same as "paste." See "How to cut and paste text" in
section 4.2.4.
Deletes the character selected with the cursor.
Moves the cursor to the top of the message being edited.
Moves the cursor to the bottom of the message being edited.
Goes to the previous page of the edit screen.
Goes to the next page of the edit screen.
Control the cursor.
Registers key input; inserts carriage return in TX message.
Chooses upper or lower case alphabet. Press and hold down the key
and then press the [Caps Lock] key to get upper or lower case alpha-
bet. Note that only upper case alphabet are used in telex.
Provides the shortcut key operation when combined with an alphabet
key. See section 2.2.4.
Inserts a space. In addition, it displays the file list, a partial view of a
file, etc., depending on the menu.
®
operating procedure.
Function
