3. SYSTEM INITIALIZATION
5. Select [MES Operation Mode] then press the Enter key to show the MES Opera-
tion window.
6. Select an operating mode, [INMARSAT-C] or [EGC]. The INMARSAT-C setting
provides telex communications and operates as an EGC receiver when the equip-
ment is not transmitting or receiving. The EGC setting enables EGC-only opera-
tion. In this case, "Current State: EGC RECEIVER" appears (reverse video) at the
bottom of the screen.
7. Press the Enter key to close the window.
8. Press the Esc key to show the [Update] window.
9. [Yes] is selected; press the Enter key to update the system settings.
10. Long-press the Esc key to return to the standby display.
3.2

PC Window Setup

The [Terminal Setup] menu provides for set up of the PC window. The set up includes
selection of connection point, date display format, screen saver on/off and window col-
ors.
1. Press the F8 and 3 keys to show the [Terminal Setup] menu.
2. Select [Connect] then press the Enter key to show the [Connect List]. This list
shows the names of the FELCOM 19s available for communication.
Note: The No. Name, IMN, IP address/subnet mask and software version of each
terminal are shown. The asterisk marks the FELCOM 19 currently selected for
communication.
3. Select the FELCOM 19 to connect then press the Enter key.
4. Select [Date Disp. Form] then press the Enter key to open its options window.
5. Select [YY-MM-DD], [MMM-DD-YY] or [DD-MMM-YY] as appropriate then press
the Enter key.
6. Select [Screen Saver] then press the Enter key.
7. Turn the screensaver ON or OFF as appropriate then press the Enter key. When
enabled, the screensaver automatically starts 10 minutes after there is no key op-
eration. To release the screensaver, press any key.
3-2
Terminal Setup
Connection
Date Disp. Form YY-MM-DD
Screen Saver
Window Color
Connection List
No. Name IMN
*01 F19_123456 123432588 172.31.16.100/24
02 F19_133234 456789210 192.168.16.11/24
03
04
05
06
07
08
09
10
OFF
IP Address Software Version
1650248-01
1650248-01
