Furuno Inmarsat Mini-C MES FELCOM19 Installation Manual
  1. Manuals
  2. Brands
  3. Furuno Manuals
  4. Touch terminals
  5. FELCOM19 Inmarsat Mini-C MES
  6. Installation manual
Furuno Inmarsat Mini-C MES FELCOM19 Installation Manual

Furuno Inmarsat Mini-C MES FELCOM19 Installation Manual

Hide thumbs Also See for Inmarsat Mini-C MES FELCOM19:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
SAFETY INSTRUCTIONS ................................................................................................ i
SYSTEM CONFIGURATION ........................................................................................... ii
EQUIPMENT LISTS........................................................................................................ iii
1. MOUNTING..............................................................................................................1-1
1.1 Antenna Unit ......................................................................................................................1-1
1.2 Communication Unit...........................................................................................................1-3
1.3 Junction Box IC-318...........................................................................................................1-4
1.4 AC/DC Power Supply Unit PR-240 (option).......................................................................1-4
2. WIRING....................................................................................................................2-1
2.1 Antenna Cable Connector at the Communication Unit ......................................................2-2
2.2 Junction Box IC-318...........................................................................................................2-7
3. INITIAL SETTINGS..................................................................................................3-1
3.1 How to Install Software ......................................................................................................3-1
3.2 How to Start Up the Software ............................................................................................3-3
3.3 How to Set the IMN (INMARSAT MOBILE NO.)................................................................3-5
3.4 How to Set up the AMS/BAM.............................................................................................3-6
3.5 PC Window Setup..............................................................................................................3-8
3.6 How to Set the Russian Language ..................................................................................3-12
3.7 How to Use the Paper Save Function..............................................................................3-12
3.8 How to Output EGC Messages........................................................................................3-12
4. HOW TO INSTALL OPTIONAL EQUIPMENT ........................................................4-1
4.2 Waterproofing Kit OP16-61 (for IC-219) ............................................................................4-2
4.3 Waterproofing Kit OP16-68 (for IC-307) ............................................................................4-4
5. HOW TO CHANGE POWER SUPPLY SPECIFICATIONS.....................................5-1
APPENDIX 1 JIS CABLE GUIDE .............................................................................AP-1
PACKING LISTS ......................................................................................................... A-1
OUT LINE DRAWINGS ............................................................................................... D-1
INTERCONNECTION DIAGRAM ................................................................................ S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
INMARSAT MINI-C MES
Model
www.furuno.com
FELCOM19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Inmarsat Mini-C MES FELCOM19 and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno Inmarsat Mini-C MES FELCOM19

Summary of Contents for Furuno Inmarsat Mini-C MES FELCOM19

  • Page 1: Table Of Contents

    5. HOW TO CHANGE POWER SUPPLY SPECIFICATIONS........5-1 APPENDIX 1 JIS CABLE GUIDE ................AP-1 PACKING LISTS ......................A-1 OUT LINE DRAWINGS ....................D-1 INTERCONNECTION DIAGRAM ................S-1 www.furuno.com All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
  • Page 2 7KH SDSHU XVHG LQ WKLV PDQXDO LV HOHPHQWDO FKORULQH IUHH )85812 $XWKRUL]HG 'LVWULEXWRU'HDOHU  $VKLKDUDFKR 1LVKLQRPL\D  -$3$1 $  -81  3ULQWHG LQ -DSDQ $OO ULJKWV UHVHUYHG +  $35    3XE 1R ,0(+ '$0, )(/&20           ...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING CAUTION Do not open the equipment Confirm that the power supply unless totally familiar with voltage is compatible with the electrical circuits and voltage rating of the equipment. service manual. Connection to the wrong power ELECTRICAL Only qualified personnel SHOCK supply can cause fire or equipment should work inside the...

  • Page 4: System Configuration

    SYSTEM CONFIGURATION ANTENNA UNIT IC-119 PRINTER POWER SUPPLY 100-115/200-230 AC/DC 1ø, 50/60 Hz Power Supply PERSONAL POWER SUPPLY LAN (Ethernet) PR-240 COMPUTER 24 VDC (PC/AT compatible) POWER SUPPLY 12-24 VDC COMMUNICATION UNIT IC-219 (with internal GPS receiver) JUNCTION BOX IC-318 Navigation Equipment (GNSS) SSAS ALERT...

  • Page 5: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Antenna Unit IC-119 w/FP16-02501, CP16-05500 Communication Unit IC-219 w/CP16-05301, SP16-01401, FP16-02700 Junction Box IC-318 For SSAS only. w/CP16-05101 SSAS Alert Unit IC-307 For SSAS only. Optional supply Name Type Code No. Remarks AC/DC Power PR-240...
  • Page 6 EQUIPMENT LISTS Name Type Code No. Remarks Hose clamp OP16-76-1 001-443-450 Nominal Diameter, Mast Diameter For 40A ( 48.6) OP16-76-2 001-443-460 Nominal Diameter, Mast Diameter For 65A to 80A ( 76.3 to 89.1) OP16-76-3 001-443-470 Nominal Diameter, Mast Diameter For 90A to 100A ( 101.6 to 114.3)

  • Page 7: Mounting

    MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Antenna Unit 1.1.1 Mounting location Refer to IMO resolutions A663(16) and A.807(19), as amended. •...
  • Page 8 1. MOUNTING 1.1.2 Mounting The antenna cable is available in lengths of 30 m, 50 m and 100 m (see table below). Cable length Type Remarks 30 m (no armor) TP5FBAW-5DFB TNC connector at both ends 30 m (w/armor) 5D-FB-CV-NP N connector on one end (antenna side) 50 m (w/armor) 8D-FB-CV...

  • Page 9: Communication Unit

    1. MOUNTING Communication Unit Select the following place to install the communication unit. • The temperature and humidity should be moderate and stable. • For maintenance and checking purposes, leave sufficient space at the sides and rear of the unit and leave slack in cables. Mounting Use two self-tapping screws (4x40, supplied) to fix the communication unit.

  • Page 10: Junction Box Ic-318

    1. MOUNTING Junction Box IC-318 The junction box IC-318 is connected to the communication unit by using the cable assy 16S0344 (2 m, attached to the junction box). Install the junction box within 2 m from the communication unit. 1. Remove four screws from the unit to separate the bottom chassis from the top chassis.

  • Page 11: Wiring

    WIRING For cable w/armor 0.34 m Ground wire Cable assy CAUTION RW-4747 TPA5FB0.4NJ5FBA-5DFB 0.4 m This unit is shipped with a 10 A fuse, which TP5FBAW-5DFB, 30 m 5D-FB-CV-NP, 30 m is for use with a 12 VDC power supply. For (No armor) 8D-FB-CV, 50 m 24 VDC power, replace the fuse with a 5A...

  • Page 12: Antenna Cable Connector At The Communication Unit

    2. WIRING Antenna Cable Connector at the Communication Unit 2.1.1 Antenna cable TP5FBAW-5DFB (30 m) Outer Sheath Inner Sheath Braided Shield Armor Remove the outer sheath, armor and inner- sheath by the dimensions shown. Set the nut, washer, gasket, clamp onto Cover with heat-shrink tubing and heat.
  • Page 13 2. WIRING 2.1.2 Antenna cable 5D/8D-FB-CV (50 m) Connector type N-P-5D-FB Dimensions in millimeters. Outer Sheath Remove outer sheath and armor by the Armor Inner Sheath Shield dimensions shown left. Expose inner sheath and shield by the dimensions shown left. Cover with heat-shrink tubing and heat.
  • Page 14 2. WIRING Connector type N-P-8D-FB Dimensions in millimeters. Outer Sheath Inner Sheath Shield Armor Remove outer sheath and armor by the dimensions shown left. Expose inner sheath and shield by the dimen- sions shown left. Cover with heat-shrink tubing and heat. Remove insulator and core by 10 mm.
  • Page 15 2. WIRING Connector type N-P-8DSFA Outer sheath 15 15 Armor Inner sheath Braided shield Twist the shield and pass the clamp. 30 30 Core Cover with heat-shrink Clamp tube or vinyl tape. Nut Washer Gasket Core (Adjust the length.) Center pin Fold back the shield.
  • Page 16 2. WIRING 2.1.3 12D-SFA-LITE-CV (100 m) Dimensions in millimeters Outer sheath Remove outer sheath and armor by the dimensions shown left. Remove inner sheath and expose shield by the dimensions shown left. Inner sheath Armor Shield Remove the insulator beneath shield by 10 mm and expose the core.

  • Page 17: Junction Box Ic-318

    2. WIRING Junction Box IC-318 Use the junction box IC-318 to connect to the communication unit. Unfasten four screws to remove the units cover to connect cables. For connection, use the optional 5 pair cable CO-SPEVV-SB-C 0.2x5P, JIS cable (Ja- pan Industrial Standard) TTYCS-4(LA) or equivalent.
  • Page 18 2. WIRING This page is intentionally left blank.

  • Page 19: Initial Settings

    INITIAL SETTINGS This chapter shows you how to setup the equipment. Some procedures require entry of job no. and password. Ask your dealer. How to Install Software After installing the equipment, install the FELCOM19 software (F19PC) in the PC as follows: 1.
  • Page 20 3. INITIAL SETTINGS 5. Enter your name and organization. 6. Click the Next button. 7. Click the Install button and the installation begins. When the installation is com- pleted, the FELCOM19 dialog box appears.

  • Page 21: How To Start Up The Software

    3. INITIAL SETTINGS 8. Click the Next button. 9. Click the Finish button. The FELCOM 19 PC application shortcut is created on the desktop. Note: To uninstall the F19 application from the PC, see the operator’s manual. How to Start Up the Software 1.
  • Page 22 3. INITIAL SETTINGS 2. Select [Internet Protocol Version 4(TCP/IPv4)] and click the Properties button. If the box to the left of [Internet Protocol Version 4(TCP/IPv4)] is not checked, place a check-mark in the box. 3. Set the IP addresses within the following range. Setting range: 172.31.16.1,172.31.16.3 to 172.31.16.254 Note: Take care that do not use the same IP address as the default IP address.

  • Page 23: How To Set The Imn (Inmarsat Mobile No.)

    3. INITIAL SETTINGS 1) Press the F8 key to show the [Setup] menu. File Edit Transmit Reports Logs Options Setup Distress StopAlarm Setup 1. System Setup 2. Editor Setup 3. Terminal Setup 4. EGC Setup 5. Auto Mode Setup 6. E-Mail Setup 7.

  • Page 24: How To Set Up The Ams/Bam

    3. INITIAL SETTINGS 4. Press the function key F8 to show the [Setup] menu. File Edit Transmit Reports Logs Options Setup Distress StopAlarm Setup 1. System Setup 2. Editor Setup 3. Terminal Setup 4. EGC Setup 5. Auto Mode Setup 6.
  • Page 25 3. INITIAL SETTINGS 5. Press the 3 key, and the Enter key. Command Window Main Menu 1. Remote Box Setup 2. External Alarm Setup 3. AMS Setup 4. Management Profile Setup Enter JOB No.: 6. Press appropriate numeric key (1 to 4), then press the Enter key. To return to the [AMS Setup Menu], press the E key at the setting window.

  • Page 26: Pc Window Setup

    3. INITIAL SETTINGS 2 key: [MY SFI Setup] Command Window Set this FELCOM’s SFI number, which is MY SFI Setup CS0001 the four-digit number that follows “CS”. (The setting range is 0001 to 9998.). Set SFI not used for other equipment. 0001 to 9998: SFI No.
  • Page 27 3. INITIAL SETTINGS 2. Select [Connection] then press the Enter key to show the [Connect List]. This list shows the names of the terminals that can be connected to the LAN interface. Connect List No. Name IP Address Software Version *01 F19_123456 123432588 172.31.16.100/24 1650248-01 02 F19_133234 456789210 192.168.16.11/24...
  • Page 28 3. INITIAL SETTINGS Preset Window Fore Color Back Color Base Window L-WHITE BLUE RCV Message Display WHITE BLACK EGC Message Display WHITE BLACK EDIT 1 BLACK GREEN EDIT 2 MAGENTA WHITE Function BLACK CYAN Sub Menu 1 BLACK WHITE Sub Menu 2 BLUE WHITE Sub Menu 3...
  • Page 29 3. INITIAL SETTINGS EDIT BASE WINDOW File Edit Transmit Reports Logs Options Setup StopAlarm < [1] UNTITLED1 > MENU CAUTION MESSAGE 3) Select [Fore Color]. 4) Use key to select a color. 5) Select [Back Color]. 6) Use key to select a color. 7) To select colors for other windows repeat steps 2)-6).

  • Page 30: How To Set The Russian Language

    3. INITIAL SETTINGS How to Set the Russian Language Do the following to create a message in Russian. 1. Press the F8 and 1 keys to show the [System Setup] menu. 2. Press ↓ to select [Command Window], and then press the Enter key. 3.

  • Page 31: How To Install Optional Equipment

    HOW TO INSTALL OPTIONAL EQUIPMENT The optional waterproofing kits OP16-58 and OP16-61 are used to protect the con- nectors on the communication unit from water splash. Note that these optional kits should be used as a couple. IPX2 Kit OP16-58 (cables)/Waterproofing Kit OP16-60 (for IC-318) OP16-58 Connect the waterproofed D-sub cables to the rear of the communication unit, instead...

  • Page 32: Waterproofing Kit Op16-61 (For Ic-219)

    4. HOW TO INSTALL OPTIONAL EQUIPMENT Attach the grommet to this notch. Color Blue Brown Purple Gray Pan head screw Green (M4x8, 2 pcs.) Attach the cover Yellow gasket to here Orange (reverse side). Pink Light-green Cable assy. 11 White (w/black dots) XM-FD-361 White (w/red dots) Black...
  • Page 33 4. HOW TO INSTALL OPTIONAL EQUIPMENT Cables connected 1. Unfasten two binding screws to detach the LAN cover from the communication unit. 2. Peel the paper and attach the LAN packing 2 (supplied with OP16-61) to the communication unit. 3. Re-attach the LAN cover. LAN packing 2 (16-023-4512) LAN cover...

  • Page 34: Waterproofing Kit Op16-68 (For Ic-307)

    4. HOW TO INSTALL OPTIONAL EQUIPMENT Waterproofing Kit OP16-68 (for IC-307) Note: To maintain the waterproofing, the unit must be installed on a bulkhead or wall, with the cable entry facing downwards. Further, the optional kit does not provide wa- terproofing if the unit is installed with the cable entry facing upwards.

  • Page 35: How To Change Power Supply Specifications

    HOW TO CHANGE POWER SUP- PLY SPECIFICATIONS The AC-DC power supply PR-240 is shipped ready for connection to a 200-230 VAC ship’s mains. If the ship’s mains is 100 VAC, change the tap connection and terminal board connection as below. Attach a label supplied as accessories to the front panel according to the ship’s mains.
  • Page 36 5. HOW TO CHANGE POWER SUPPLY SPECIFICATIONS This page is intentionally left blank.

  • Page 37: Appendix 1 Jis Cable Guide

    EX: TTYCYSLA - 4 MPYC - 4 TTYCSLA-4 Core Area (mm Designation type Designation type # of cores The following reference table lists gives the measurements of JIS cables commonly used with Furuno products: Cable Core Cable Core Diameter Diameter...
  • Page 44 Y.NISHIYAMA 17/May/2012...
  • Page 45 Y. NISHIYAMA 6/Oct/2010...
  • Page 48 Y.NISHIYAMA 17/May/2012...
  • Page 49 Y.NISHIYAMA 30/Apr/2012...
