How To Edit The Station List; How To Print The Station List; How To Enter Position - Furuno FELCOM19 Inmarsat Mini-C MES Operator's Manual

2. Enter the recipient's mobile phone number, beginning with the country code, then
press the Enter key.
3. Select [Remarks] then press the Enter key.
4. Enter remarks then press the Enter key. A max. of 20 characters can be used.
5. Press the Esc key to return to the station list.
6. To enter another SMS recipient, repeat the procedure from step 2 on page 3-15.
7. Long-press the Esc key to return to the standby display.
3.7.2

How to edit the station list

1. Press the F8, 8 and 1 keys to display the [Station List].
2. Select a station then press the Enter key.
3. Do one of the following:
Change station name: Select [Station Name] then press the Enter key. Press the
BackSpace key to erase name, enter new name then press the Enter key.
Delete station name: Select [Station Name] then press the Enter key. Press the
BackSpace key to erase name then press the Enter key.
4. Press the Esc key to save the changes.
5. Long-press the Esc key to return to the standby display.
3.7.3

How to print the station list

1. Press the F8, 8 and 1 keys to display the [Station List].
2. Press the P key while pressing the Ctrl key.
3. Long-press the Esc key to return to the standby display.
3.8

How to Enter Position

When there is no navigation data, enter ship's position manually as follows:
1. Press the F7 and 1 keys.
2. Press the Enter key to open the latitude en-
try window.
3. Enter latitude (XX°XX.XX), press the N or S
key as appropriate then press the Enter key.
4. Select [LON], press the Enter key, enter longitude (XXX°XX.XX), press the E or
W key as appropriate then press the Enter key.
5. Select [Update Time] then press the Enter key. Enter the current time then press
the Enter key.
6. Press the Esc key to open the [Update] window.
7. [Yes] is selected; press the Enter key to update position and close the menu.
The position entered appears at the bottom right corner of the system status monitor
screen.
3. SYSTEM INITIALIZATION
Ship Position
LAT 34:30.00N
LON 135:00.00E
Update Time 09:40 11-11-12 (YY-MM-DD)
3-17
