rev.09 MCR41-MCR42 User Manual
M
AIN FEATURES
MCR41/42(*) is a camera dual true diversity wireless-microphone receiver system in a modular
stand-alone or slot-in configuration (compatible with most camera's slot):

Extreme RF (radiofrequency) performances and reliability

Extreme frequency agility (tuning windows up to 240 MHz with independent tunable
filters on 2 ch's):
MCR42-L: 470÷678 MHz
MCR42-H:590÷822 MHz
MCR42-N 470÷700 MHz
MCR42-M: 566÷798 MHz
(extended range up to 830 available on request and upon your country-specific
regulations)

digital output on AES3

multi-companding compatibility

future digital functionality enhancements

Automatic scan for best channels, squelch and other automatic setup

Infrared interface (i.e. for system setup, microphone programming)

Automatic transmitter re-programming (thru infrared, sync function)

Push to Talk (PTT) function with additional audio output signals (patented)
(*) Note MCR41 is the version with only one diversity RX board mounted. It supports all features of
MCR42 and is compatible with MCR42 Firmware.
It is also possible to mount the second Rx board to upgrade a MCR41 to an MCR42.

Technical description

The MCR42 is a professional dual true diversity receiver for wireless microphones reception
especially designed for broadcast production, live stages, theatres and top professional
applications.
It's winning performances are:

High immunity on strong RF environment

Huge switching bandwidth

High audio performances and flexibility with analog or digital processors

High reliability and durability
One of the milestones in the design of the MCR42 is high reliability: most of the circuitry of the
receiver is independent one from each other.
