MAIN FEATURES

Two channels diversity receiver
DSP analogue Output (AES3)
Up to 790 MHz bandwidth in 470/1260 MHz range
Next Gen Multiband front-end filtering:
o
High Q moving filter in 470-960 MHz
o
High Q moving filter in 960-1160 MHz (DME)
o
Country specific saw filters:
USA 940-960 MHz &
Japan 1240-1260 MHz or 806-810MHz
Wideband and Narrowband DSP-FM operation (SW selectable):
o
Narrowband allows more 50% band efficiency
o
Narrowband allows about 3dB extra sensitivity and noise immunity
Extreme low noise VCO with ultrafast spectrum scan for optimal quick & easy setup
High contrast OLED display
Automatic scan & transmitter programming through infrared
DSP based for extreme flexibility and multi-companding operations
Miniature design with integrated battery pack:
- rechargeable lithium pack
- 2 x AA batteries
Operation and charger (lithium) thru USB connector
Monitor & control through USB and Wisycom Manager 2.0 (computer SW):
o
This transform MPR52 in a quick and low noise portable spectrum scanner
potential interferences coming from having the ultra-wide band, must use frequencies included
into a 30 MHz filter range.
Please note that the two channels, in order to protect them from
