Network Interface Connection
Network Interface Connection

P1485(M) Dip Switch Configuration

ON KSDO4H
ON KSDO4H
ON KSDO4H
ON KSDO4H
* Please refer the corresponding Central Controller installation manual if you want to know whether
your Central Controller is compatible with LGAP or not.
CAUTION:
The wrong setting of air-conditioner switch could cause malfunctioning.
Switch setting must be done carefully.
8 PC Central Controller
& MPS MULTI Products Configuration Methods
1 ON, All others OFF:
1 and 4 ON, All others OFF:
2 ON, All others OFF: MPS Multi Standard Product + Central Controller
2 and 4 ON, All others OFF: Multi Standard Product + Central Controller
Conditioner Type
* LGAP : LG Air conditioner Protocol
& MPS
Inverter Product + Central Controller (All types) -
Without LGAP
Inverter Product + Central Controller (All types) -
Using LGAP
(All types) - Without LGAP
(All types) - Using LGAP
Select Air
Select Network
Type
ON KSDO 4H
& MPS
