I Network Interface Connection; P1485(M) Dip Switch Configuration - LG PC Central Controller Installation Manual

Network Interface Connection
Network Interface Connection

P1485(M) Dip Switch Configuration

ON KSDO4H
ON KSDO4H
CAUTION:
The wrong setting of air-conditioner switch causes malfunctioning of the whole system.
Switch setting must be done carefully.
8 PC Central Controller
& MPS MULTI Products Configuration Methods.
1 and 4 On, All others Off:
2 and 4 ON, All others OFF: Multi Standard Product + With LGAP
Select Air
Conditioner Type
ON KSDO 4H
* LGAP : LG Air conditioner Protocol
& MPS inverter product +
With LGAP central controller
Ex) PCC(PQCSS513A0)
central controller
Ex) PCC(PQCSS513A0)
Select Network
Type
