I
Using Wireless Remote Controller
ON
OFF
SET
CANCEL
PLASMA
❈ Some remote controllers may not support above functions according to the production date of
wired/wireless remote controllers. As it has no concern with customer's use, use the remote
controller available for the address setting during installation.
❈ The remote controller having this function will be given with the purchase of central controller.
1. Address setting mode
1) Keep pressing upper left side key continuously and press
RESET button once. Now the system is ready for address
setting.
2) Set the Indoor unit address using the temperature controller
buttons.
Allowed Range : 00-FF
ex)
3
Address
check
Address
A
setting
3) After setting address, press ON/OFF key once towards
Indoor unit.
4) The Indoor unit shows the set address and it means
completion of address setting process. (The address
displaying time and its way can depend upon the type of
Indoor unit )
2. Address check mode
1) Keep pressing upper right side key continuously and press
RESET button once. Now the system is ready for address
checking.
2) Press ON/OFF key once toward the Indoor unit which shows
set address on the display.(The address displaying time and
its way can depend upon the type of Indoor unit )
3) Reset the remote controller to use it for normal operation
mode.
The Indoor Unit Address Setting method
Group No.
Indoor unit No.
Installation Manual 13
