Installation
Before drilling any holes check that the area behind the surface to be drilled is clear of any
electrical cables, pipes etc. The ceiling must take a weight bearing of at least 40kgs weight.
Whenever possible protect the Rangehood with a fabric sheet or similar.
When installing the rangehood, the lower edge of the unit must be a minimum of 600mm (650mm for
gas cooker) above the cooking range. The recommended position for the hood is 650mm above the
hotplates.
Pictured: Minimum height from the hob surface to the underside face of the rangehood is:
600mm for electric hob, 650mm for gas hob
Notes: If the instructions for the gas hob specify a greater distance, this has to be taken into account.
Any installation above 750mm will compromise performance.
