Installation and Operating Instructions

Issue 1

Issue

Description

: Robinhood Powerpack Rangehood with LED Panel

Model Number : RPL3CL52BK (52cm), RPL3CL75BK(75cm) & RPL3CL90BK(90cm)

Model Pictured: RPL3CL52BK

Model Pictured: RPL3CL75BK

Model Pictured: RPL3CL9BK

*Actual unit may vary from above model pictured

Table of Contents

Need help?

Do you have a question about the RPL3CL52BK and is the answer not in the manual?

Questions and answers

Summary of Contents for ROBINHOOD RPL3CL52BK

Page 1 Installation and Operating Instructions Issue 1 Issue Description : Robinhood Powerpack Rangehood with LED Panel Model Number : RPL3CL52BK (52cm), RPL3CL75BK(75cm) & RPL3CL90BK(90cm) Model Pictured: RPL3CL52BK Model Pictured: RPL3CL75BK Model Pictured: RPL3CL9BK *Actual unit may vary from above model pictured...
Page 2: Table Of Contents
Contents Congratulations! Thank you for choosing one of our appliances. Before you use the appliance, we strongly recommend that you read through the whole user manual which provides important safety instructions and description of the product and the proper use of its functions. To avoid the ever‐present risks involved with using an electrical appliance it is vital that the oven is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards.
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT: Read the assembly instruction section and safety precautions of this booklet carefully before removing the contents of this carton. 1. All electrical work must be done by a registered electrician in accordance with local and national electrical codes as applicable.
Page 4: Appliance Details
Appliance Details Voltage & Frequency: 220 - 240Vac 50Hz Model RPL3CL52BK RPL3CL75BK RPL3CL90BK 1 x 22W LED Panel 1 x 25W LED Panel Lamp Max: 1 x 15W LED Panel 167 W 170 W Rated Input Power: 160 W Contents of packaging: Typical equipment required: •...
Page 5: Installation Instructions
Installation Instructions General Information Before installing and operating the rangehood, carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations. Vent Installation 1. The cooker hood should be placed at a distance of 60-75 cm from the cooking surface for the best effect. 2.
Page 6 Installation Instructions Fix the expansion pipe on the outlet with cable tie. See pic 3. Note: The expansion pipe is not included in the product, and it needs to be purchased separately. WARNING: ➢ For safety reason, please use only the same size of fixing or mounting screws which are recommended in this instruction manual.
Page 7: Operation Instructions
Operation Instructions Touch control with LED display There are five touch buttons: (Timer), (Decrease), (Power), (Increase), (Lamp).See Pic above. 1. Power on: After you have connected the cooker hood to the mains supply, all the outputs will close, all indicator lights of the buttons will lit on, and the cooker hood will enter to standby state. 2.
Page 8 Operation Instructions 5. Decrease button” ”: Press decrease button” ”, the cooker hood will decrease one speed, and the display will show the current working speed, the indicator light of the decrease button will on. When press decrease button again when it is working at the low speed, the LED display will show “0”, the cooker hood will turn off and the indicator light of the decrease button will change to backlight status.
Page 9: Troubleshoot
Troubleshooting Fault Possible Cause Solution Fan switch turned off Select a fan switch position. Light on, but motor Fan switch failed Contact service center. does not work Motor failed Contact service center. House fuses blown Reset/Replace fuses. Light does not work, Refit mains power cable to power Mains power cable is loose or motor does not work...
Page 10: Cleaning And Maintenance
Cleaning and Maintenance Caution: • Before maintenance or cleaning is carried out, the cooker hood should be disconnected from the mains power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. • External surfaces are susceptible to scratches and abrasions, so please follow the cleaning instructions to ensure the best possible result is achieved without damage.
Page 11: Bulb Replacement
Cleaning and Maintenance INSTALLING GREASE MESH FILTERS To install filters for the following four steps: - Angle the filter into the slots at the back of the hood. - Push the button on the handle of the filter. - Release the handle once the filter fits into a resting position. - Repeat to install all filters.
Page 12 Cleaning and Maintenance WARNING: The bulb must be replaced by the manufacturer, its service agent or similarly qualified persons. Before changing the lights, make sure that the appliance is unplugged from the power source and that the lamps are cool. Changing the lights: 1.
Page 13: Warranty Certificate (New Zealand)
The following conditions apply in respect of the warranty given in this certificate: 1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of: Rangehood, Ovens, Cooktops, Dishwashers - 24 months from date of original purchase for domestic use.
