- Page 1 SH 1000/513 TC SH 1400/610 TC SIDE-POWER Thruster Systems Installation and user's manual Installasjon og brukermanual Mechanical thruster installation only SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 w w w. s i d e - p o w e r. c o m Fax:+47 69 30 00 70 sidepower@sleipner.no...
-
Page 2: Table Of Contents
USER'S MANUAL Technical specifications ............3/4 Important user precautions ............20 Planning & important precautions..........5 How to use Side-Power thrusters ..........20 Tunnel installation Warranty statement .............. 21 Positioning of the tunnel / thruster ..........6 Spareparts list & drawing ............ 22 How to shape the tunnel ends ........... -
Page 3: Technical Specifications
Port side Starboard side METRIC IMPERIAL SH1000 SH1400 SH1000 SH1400 Light duty thrust [kg] 1200 1600 Light duty thrust [lbs] 2646 3527 Heavy duty thrust [kg] 1000 1400 Heavy duty thrust [lbs] 2205 3086 A [mm] A [in] 20.2 B [mm] B [in] 19.1 19.7... - Page 4 Requirements / Hydraulic hose connections to motor Port A Port B Drain port (Must be installed) Motor type Port A/B Port flange threads Drain port 1 1/4" BSP 1/4" BSP 1 1/4" BSP 1/4" BSP BA80 1" 6000 PSI SAE J518/ ISO 6162 Code 62 7/16-14 UNC-2B 19 deep 7/8"-14 UNF BA90...
-
Page 5: Planning And Important Precautions
Planning and important precautions Prior to installation, it is important that the installer reads this guide to ensure necessary acquaintance with this product. This manual is intended to support educated / experienced staff and is therefore not sufficient in all details for the correct installation. If the height in the room you are installing the Sidepower is limited, the Sidepower can be installed horizontally or at any angle in between. -
Page 6: Positioning Of The Tunnel / Thruster
Fig. 1 Fig. 3 Fig. 2 Fig. 4 Positioning of the tunnel / thruster Plassering av tunnel og thruster The Thruster should be as far forward as possible (Fig. 1) Tunnelen bør plasseres lengst mulig frem i baugen (Fig. 1) Because of the leverage effect around the boats pivot point, it is For å... -
Page 7: How To Shape The Tunnel Ends
NB! Propellene til Side-Power thrustere kaviterer ikke på arbeid- This "free" additional thrust can in optimal installations be as shastighet, så kavitasjon og støy som oppstår som følge av much as 30 - 40% of the total thrust. -
Page 8: How To Prevent Drag From Tunnel Installation
Fig. 1 Fig. 2 Fig. 3 Prevent drag from tunnel Motstand forårsaket av tunnel A possible problem in sailboats or fast powerboats, is that they Et mulig problem for seilbåter eller meget hurtiggående båter er get a drag from the back face of the tunnel, as this becomes a motstand i tunnelen. -
Page 9: Possible Tunnel Installation In Sailboats
Fig. 1 Pos. A Pos. B Tunnelinstallasjon på seilbåter Tunnel installation in sailboats Many sailboats have a racing type hull which means that it is very Mange seilbåtskrog er bygget for å oppnå høy fart. De har brede flat bottomed and has a very shallow draft in the bow section. -
Page 10: Series Production Installation
Fig. 1 Fig. 2 Radius = D x 0,1 a1 a2 a1 a2 Fig. 4 Fig. 3 Series production installation Installasjon ved serieproduksjon Boat builders having thrusters as standard, or delivering a large Båtbyggere som har trustere som standard eller leverer en eller portion of one or more models with thrusters, have the opportu- flere modeller med valgfri truster i stort antall har mulighet for å... -
Page 11: Tunnel Installation In A Grp Boat
Fig. 2 Fig. 1 Fig. 4 Fig. 3 Tunnel installation Tunnelinstallering We recomend that a professional does the fibreglass fitting Sleipner Motor anbefaler at innstøping av glassfibertunnelen of the tunnel. These instructions are only general, and do not utføres av kyndig personell. Denne instruksjons manua- explain in any way the details of fibreglass work. - Page 12 å gjøre glassfiberen vanntett. NB ! All original Sidepower tunnels are fully waterproof NB ! Alle originale Side-Power tunneler er vanntette ved leve- when they are delivered. ring! This means that unless you want, because of special reasons, to Så...
-
Page 13: Thruster Installation Gearhouse And Motorbracket
Fig. 2 Fig. 1 Tighten to 60Nm SM-100537 70 1241 AISI 304 SM-100029 St 52 SM-100028 Default SM-100027 Default SM-100026 Default SM-100024 SS1914-04 SM-100004 St 52 DIN 472 - 80 x Steel, Mild 2,5 Steel, Mild DIN 472 - 55 x 2 Steel, Mild Steel, Mild DIN 471 -... -
Page 14: Propeller
Fig. 1 Apply Molycote paste or similar on shaft before fitting propeller Fig. 2 Tighten to 400Nm Side marked "P" Side marked "S" facing PORT facing STARBOARD Propeller Propeller marked LH marked RH Fitting propellers Montering av propeller 1. Turn the propeller shaft so that the key (6) is in a horizontal 1. -
Page 15: Hydraulic Motor
Fig. 1 Fig. 1a Fig. 1b Fig. 2 ... -
Page 16: Oil Tank
>0,2 x d Waterline Tunnel center line i a l i a l Fitting oil tank Montering av oljebeholder 1. Fit the oil tank (1) above the waterline by at least 20% of the 1. Plasser oljebeholderen (1) over vannlinjen, minst 20% av distance from the waterline to the centre of the tunnel. -
Page 17: Hydraulic Installation
Hydraulic motor Cross-over valve (Ref. Hydraulic system drawings/system manual for installation) Mounting plate Motor bracket for holding motor and gear leg together on the tunnel. Flexible coupling secures the motor if propeller is jammed. Changeable from inside the boat. -
Page 18: Maintenance & Service
Oil drain screw with washer Keys Washer Propeller lock nut Zinc anode Screw for zinc anode Vedlikehold Maintenance There must always be oil in the oil reservoir. Refill if necessary Det må alltid være olje i oljebeholderen. Etterfyll om nødvendig with gear oil GL-5. -
Page 19: Checklist For Control Of The Installation
Checklist (only for thruster) Sjekkliste (Kun truster) Propellen er festet til akselen på korrekt vis. Propeller is fastened correctly to the shaft. Propellen roterer fritt i tunnel. Propeller turns freely in tunnel. Girhuset er fylt med korrekt olje. Lower-unit is filled with gearoil. -
Page 20: Important User Precautions
How to use Sidepower thrusters Hvordan bruke Side-Power trustere 1 Turn main power switch for the bowthruster on / make sure 1 Skru på hovedbryeren og sjekk at den hydrauliske pumpen fungerer that the hydraulic pump is running. -
Page 21: Warranty Statement
Warranty statement 1. The equipment manufactured by Sleipner Motor AS (The “Warrantor”) is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 22: Spareparts List & Drawing
SH1000/513TC- SH1400/610TC 1.3 - 2012... - Page 23 SERVICE SH1000/513TC- SH1400/610TC 1.3 - 2012...
-
Page 24: Service Centres
Fax: +44 1364 649 399 www.imtra.com Fax: +385 51 704 600 andy@sleipner.co.uk side-power@imtra.com acyachting@gmail.com Sleipner Motor AS • P. O. Box 519, N-1612 Fredrikstad • Norway Tel: +47 69 30 00 60 • Fax: +47 69 30 00 70 • sidepower@sleipner.no • www.side-power.com...
