SIDE-POWER
Thruster Systems
Installation and user's manual
EN
Installations- und Bedienungsanleitung
D
Mechanical thruster installation only
SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
www.side-power.com
SH 100/185 T,
SH 160/215 T ,
SH240/250TC, SH320/300TC
SH420/386TC, SH550/386TC
Document id:
Revision:
2746
13
© Sleipner Motor AS 2018
