Operating Instructions

2) Place the work piece on the table and lower the
guard so its just above the work piece.
3) Switch on the scroll saw by pressing the 'GREEN
ON' button, see fig 17.
4) Increase the speed to 400rpm, supporting the
work piece with both hands slowly guide the work
piece forward into the blade, see fig 18.
NOTE: You must guide the wood into the blade
SLOWLY, because the teeth are very small, and it
cuts ONLY on the downward stroke. If you push
the wood into the blade too rapidly, you can easily
break the blade.
NOTE: If you find the blade is struggling to cut
through, increase the speed by turning the variable
speed knob.
Fig 17-18
5) Once you have completed your cut, switch off the
scroll saw by pressing the red 'OFF' button.
6) If you have finished using the scroll saw, clean
above and below the work table and using a damp
cloth wipe the scroll saw over.
7) If the scroll saw is not going to be used for a period
of time, smear a light coat of oil over the work table to
prevent the table from rusting and place a dust sheet
over the scroll saw.
Tilting the table to 45˚
1) Loosen the table's butterfly clamp and rotate the
table to + /- 45˚ degrees and re-tighten clamp, see
fig 19.
2) Place the work piece on the table and set the
guard so it's just above the work piece, see fig 20-21
Guard
14
Fig 19
Fig 20-21
Work piece
