VIPET-FRAME
CONTROL PORT
5
Control signals, outputs, 12V DC and fault relay contacts.
POWER
6
Power switch.
EXP. 1
7
RS485 Port for connection to ASL Microphones, BMB01 Remote I/O Units, or OEM equipment.
By default one RS485 interface (COM4/ttyS3) is available on this port. A second interface
(COM2/ttyS1) can be enabled by disabling the RS232 interface on the EXP. 2 port.
EXP. 2
8
RS232 Port for connection to modem (COM2/ttyS1).
This interface can be disabled by removing a link on the Watchdog Card (see Figure 4).
PCI 1
9
PCI 2
10
Standard Audio Line-In (3.5mm jack)
11
Standard Audio Line-Out (3.5mm jack)
12
Standard Microphone Input (3.5mm jack)
13
ETH0
14
Standard LAN Port (RJ-45 socket).
ETH1
15
Standard LAN Port (RJ-45 socket).
USB1 to USB4
16
Standard USB 2.0 Port (4x) (USB series "A" socket)
COM1
17
RS232 Port for connection to ASL Router.
Linux port name: ttyS0
LPT1
18
Standard Parallel Output (25-WD female connector)
Standard VGA Output (9-WD female connector)
19
Standard PS2 Keyboard Connector (6-pin female PS2 connector)
20
Standard PS2 Mouse Connector (6-pin female PS2 connector)
21
VIPET-AUDIO-4/8
Optional Audio I/O:
9
•
VIPET-AUDIO-4: Audio Card with 4 inputs and 4 outputs. 15-WD male connector
•
VIPET-AUDIO-8: Audio Card with 8 inputs and 8 outputs. 44-WHD female connector
On the 8x8 Audio Card a second connector is available (15-WHD female) but it is not used.
•
A second optional Audio Card can be connected to PCI slot
•
Refer to the VIPET-AUDIO-4/8 & BOB08 Product Manual.
