Installation

Equipment and Tool Requirements
•
The VIPET unit, with pre-installed hardware and software options.
•
The VIPET-SERIAL-4 (RS485 port expander), BOB08 / BOB04 Audio Breakout Box, etc., if used.
•
A small flat-bladed screwdriver.
•
A pair of wire cutters/strippers.
•
A soldering iron.
•
A standard 19-inch rack wired and configured with equipment to be controlled by the VIPET (e.g. DSP
Router), cabling for power supply, wiring for signal monitoring, RS232 and RS485 cabling and/or other
cabling as appropriate.
External Cabling Requirements
Connection
Ethernet Ports (ETH0 and ETH1)
Control Port
VIPET-FRAME
RS232 Port (COM1 and EXP. 2)
RS485 Port (EXP. 1)
230V AC mains power supply input
VIPET-PSU-MAINS
VIPET-PSU-24V 24V DC power supply input
VIPET-AUDIO-4/8 Refer to the VIPET-AUDIO-4/8 & BOB08 Product Manual.
VIPET-SERIAL-4 VIPET USB to RS485 port expander
VIPET - Hardware Installation and Maintenance Guide
The VIPET requires a mains filter for EMC compliance, and for protection against
voltage surges.
!
!
The VIPET mains filter needs to be ordered as part of the VIPET system, as ASL
item VIPET-MAINS-FILTER, and should be installed as shown in Figure 3.
U-0582-0512.doc – Issue: 05 complete, approved
Termination and Suggested Type
Standard unscreened LAN cable.
Cabling connector: 25-WD male connector.
Cabling as per connected device specification.
Cabling connector: 9-WD female connector.
Cabling as per ASL Router specification.
Cabling connector: 9-WD male connector.
Cabling as per controlled device specification.
Installation cabling connector: IEC320 socket.
Normal standard mains cabling installation. Current
rating to suit particular installation.
Installation cabling connector: pluggable male Wago
cage clamp (Wago 231-632).
Standard cable rated for 2 A.
USB cable is supplied.
If an alternate cable is required, use high quality
shielded cabling for EMC compliance.
