Control Port

5
RL1-NC
1
14
RL1-C
2
15
RL1-NO
3
16
RL2-NC
4
17
RL2-C
5
18
RL2-NO
6
19
GND
7
20
GND 8
21
+12V
9
22
+12V
10
23
11
24
12
25
13
COM1 Connector – RS232
17
GND
5
9
DTR
4
8
TXD
3
7
RXD
2
6
1
•
Standard RS232 interface
•
Linux port name: ttyS0
•
Used for the connection to the ASL
Router
VIPET - Hardware Installation and Maintenance Guide
Pin No.
1
RL1-NC
2
3
RL1-C
4
RL1-NO
5
RL2-NC
6
7
RL2-C
8
RL2-NO
9
10
11-13
14
15
16
17
18
19
20-25
!
!
Pin No.
1
2
3
CTS
4
RTS
5
6
7
8
9
!
!
U-0582-0512.doc – Issue: 05 complete, approved
Page 14 of 24
25-Way D female connector
Signal
Normally closed contact from System Fault relay 1
Changeover contact from System Fault relay 1
Normally open contact from System Fault relay 1
Normally closed contact from Fault relay 2
Changeover contact from Fault relay 2
Normally open contact from Fault relay 2
Ground
Ground
+12V fused at 200mA
+12V fused at 200mA
Reserved
Normally closed contact from System Fault relay 1
Changeover contact from System Fault relay 1
Normally open contact from System Fault relay 1
Normally closed contact from Fault relay 2
Changeover contact from Fault relay 2
Normally open contact from Fault relay 2
Reserved
Do not make connections to reserved pins on this
connector.
9-WD male connector
Signal
Not connected
RS232 Received Data
RS232 Transmitted Data
Data Terminal Ready
Common Ground
Not connected
Request To Send
Clear To Send
Not connected
Do not make connections to reserved pins on this
connector.
