LED Behavior

Function LED Behavior
Power Steady On
Power Unlighted
Status
Steady On
Status
Unlighted
Status
Status Blinking
Internet
Steady On
Internet
Unlighted
WPS
WPS
Description
Normal Operation
Power off
1. Connect to switch by
Ethernet or WiFi.
2. Reset to default.
1. Power off
2. No connection
1.While F/W upgrading
2.While WiFi site survey
performing
1.While network
connection in progress
2. Restoring settings.
Connect to Internet
1. Power off
2. No connection
WPS in progress
WPS Error
- 4 -
Remark
Top
(Blue)
Top
(Blue)
Second (Blue)
Second (Blue)
Second (Blue)
Second (Blue)
Third (Blue)
Third (Blue)
WCB-100A
Fourth (Blue)
WCB-100A
Fourth (Blue)
