UDP - This protocol allows for more real-time audio and video streams. However, network
packets may be lost due to network burst traffic and images may be broken. Activate UDP
connection when occasions require time-sensitive responses and the video quality is less
important.
/ Recording on/off: shows the status of recording video
/ MIC on /off: shows the status of MIC volume.
/ MD on/off: shows the status of Motion Detection
Camera Control Panel - There are two slider bars and eight control buttons on the remote
controller. They are describe as below:
Brightness and Mic volume adjustment - Drag the slider bar to adjust the image
brightness level and Mic volume. Click "Default" for default brightness setting and "Mute"
for no sound. For more Audio setting, please refer to the Audio configuration on page 26.
Speaker –The build-in speaker plays the sound of an audio clip from computer MIC when
it is enabled.
Play or Stop - Click this button to play or stop the video.
Recording - Click this button to record video to your computer.
Snapshot - Click this button to capture and save still images.
Digital Zoom - Click this button to enable the zoom operation.
Mirror - horizontally reflect the display of the live video.
Flip - vertically reflect the display of the live video.
- 19 -
