Specifications - Unitron MEC2 Manual

SPECIFICATIONS

Optical System
Viewing Tube
Eyepiece
Nosepiece
Objective
Focusing System
Stage
Mechanical Ruler
Illumination
Filters
OBJECTIVES
Magnification
5x
10x
20x
40x
®
UNITRON
MEC2 INVERTED METALLURGICAL MICROSCOPE
Infinity Optical System
Siedentopf style; Trinocular Tube; Inclined 30º; Diopter Range: ±5;
Interpupillary distance range: 48mm -75mm
Standard configuration light distribution: Binocular 100% or
Binocular/photo 20%/80%
Extra Wide Field 10x with 20mm field of view with diopter adjustment and
eyeguards
Quintuple nosepiece with positive click stops
Plan achromatic objectives: 5x, 10x, 20x, 40x
Coaxial coarse and fine focusing adjustment; Vertical objective movement;
Coarse focus: 377mm per roation; Fine focus: 0.2mm per rotation
Area: 160mm x 250mm
X/Y Coaxial Control; Right hand low position
Movement range: 120mm x 78mm
6 volt 30 watt halogen; variable intensity;
External lamp housing for Kohler illumination
Blue, yellow, green and ground glass
Aperture Number
(N.A.)
0.12
.25
0.4
0.6
73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com
Working Distance
(mm)
15.4
11
6
3.7
Conjugate Distance
(mm)
16
