SPECIFICATIONS

Optical System
Observation Method
Focusing
Eyepiece
Nosepiece
X – Y Travel
Illuminator
Filters
Dimensions &
Weight
Warranty
Accessories
®
UNITRON 73 Mall Drive, Commack, NY 11725 • 631-543-2000 • www.unitronusa.com
Unitron® plan achromat 5x, 10x, 20x and 50x objectives are standard. Optional 40x, 60x and
80x objectives are available
Brightfield
Rack and Pinion coarse focus 60mm vertical travel with precise micrometer screw fine focus
mechanism
eyepiece with built-in diopter adjuster, 22mm field of view and 10mm/100 division crossline
reticle
Quadruple revolving nosepiece
Rack and pinion controls for graduated movement. Stand will move 40mm (X) and 50mm (Y)
Variable 6 volt 20 watt Koehler type vertical halogen illuminator with field diaphragm for both
AC and DC operation
Green and yellow filters are standard. A filter slot is built-into the illuminator housing
Physical weight & dimensions: 9 lbs.; 9" x 11" x 10" (WDH): Shipping weight and dimensions:
28 lbs.; 21" x 14" x 16"
5 year limited warranty, instruction manual and dust cover are supplied with each complete unit
Micrometrics® CCD and CMOS digital c-mount cameras with measurement and materials
software
Digital still cameras, analog color and black and white cameras
Video c-mount adapters: 0.5x, 0.67x, and 1x magnifications
Reticles: Grain size, crossline, grid, metric, inch, austentite and custom patterns are available
Stage micrometers in inch or metric rulings with N.I.S.T. traceability are available
RMM2 ROLLSCOPE MICROSCOPE
