Filling the LP Cylinder

The Revolution uses the 20lb (9.1 kg) capacity cylinder,
which meets the D.O.T. 4E240 standards. These cylinders
are also listed by UL. In addition, the steel cylinder meets
European TPED specifications and is CE compliant.
Filling should be done ONLY by a qualified propane dealer.
A properly filled cylinder should not exceed 80% of the
rated capacity. Do not overfill the cylinder or use a liquid
withdraw cylinder on the machine. The use of a liquid
withdraw cylinder on a vapor withdraw system could freeze
the regulator and create a fire hazard.

Installing the LP Cylinder

®
Place the Safe-Fill cylinder on the cylinder platform at the
back of the machine. Connect the fuel hose coupling to
the service valve by turning to the right (clockwise). HAND
TIGHTEN ONLY! Make sure coupling is not cross
threaded and check for leakage by noting any propane
odors immediately after cylinder is connected. Finally,
connect the two ends of the tank strap together.
To Remove the LP Cylinder
procedure. Always connect or change cylinders in a
well-ventilated area.
, reverse the above
