O p e r a t o r ' s M a n u a l
U H S P r o p a n e B u r n i s h e r
Failure to read and understand this manual before
operating this machine or performing service on this
machine may result in injury to the operator or nearby
personnel or result in damage to the machine or
nearby property. Each operator must be trained in the
operation of this machine before being allowed to use
it. Contact Amano Pioneer Eclipse Customer Service
at 1-800-367-3550 or 1-336-372-8080 or an authorized
Amano Pioneer Eclipse Distributor to inquire about
training or to request a replacement manual.
La falta de leer y de entender este manual antes de
usar esta máquina o de realizar servicio en esta
máquina puede dar lugar a lesión al operador o al
personal próximo o a resultado en daño a la máquina
o propiedad próxima. Cada operador debe ser
entrenado en la operación de esta máquina antes de
ser permitido utilizarla. Ponerse en contacto con el
servicio de Amano Pioneer Eclipse 1-800-367-3550 o
1-336-372-8080 o un distribuidor autorizado por
Amano Pioneer Eclipse para investigar sobre el
entrenamiento o para solicitar un manual.
Manquer de lire et de comprendre ce manuel
d'utilisation avant l'utilisation de cette machine ou
avant faire de maintenance sur la machine peut être
résulter en blessure à l'opérateur ou au personnel
proche ou peut endommagé la machine ou la propriété
proche. Chaque utilisateur doit être entraîné dans
l'opération de cette polisseuse avant l'utilisation.
Veuillez contacter le service àpres-vente de Amano
Pioneer Eclipse à 1-800-367-3550 ou 1-336-372-8080
et/ou un distributeur de Amano Pioneer Eclipse pour
vous renseigner concernant l'entraînement ou pour
obtenir un autre manuel d'utilisation.
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Pioneer Eclipse revolution REV24NXG
Summary of Contents for Pioneer Eclipse revolution REV24NXG
- Page 1 Chaque utilisateur doit être entraîné dans l'opération de cette polisseuse avant l'utilisation. Veuillez contacter le service àpres-vente de Amano Pioneer Eclipse à 1-800-367-3550 ou 1-336-372-8080 et/ou un distributeur de Amano Pioneer Eclipse pour vous renseigner concernant l'entraînement ou pour obtenir un autre manuel d'utilisation.
- Page 3 DANGER! For your safety, if you smell gas: DANGER! 1. Extinguish any open flame. Do not store or use gasoline or other 2. Open window. flammable vapors and liquids in the vicinity 3. Do not touch electrical switches. of this or any other appliance. 4.
-
Page 4: Table Of Contents
Contents Quick Reference Specifications..........2 Machine Maintenance............24 Safety Precautions............. 3 Clean Dust Container Filter........24 Machine Preparation............7 Inspect Pads and Pad Holders......24 Unpacking the Machine.........7 Inspect Drive Belt..........24 Filling the LP Cylinder..........8 Replace Drive Belt..........25 Installing the LP Cylinder........8 Battery Maintenance..........25 Machine Components............ -
Page 5: Quick Reference Specifications
- 24” Natural Poly-Blend: PD002024 - 28” Blue Blend: PD006028 - 28” White Lightning: PD010028 - 28” Thermal Thunder: PD001428 - 28” Natural Poly-Blend: PD002028 Your Authorized Amano Pioneer Eclipse Distributor Authorized Amano Pioneer Eclipse Distributor Telephone Number Amano Pioneer Eclipse Customer Service: 1-800-367-3550... -
Page 6: Safety Precautions
Safety Precautions NOT allow the machine to run unattended. DO NOT leave Anyone operating the machine should read the the machine in a place where unauthorized or untrained following carefully and be informed of potentially personnel could use the machine. DO NOT run the dangerous operating conditions. - Page 7 Use only replacement parts machine. supplied by Amano Pioneer Eclipse or an Amano Pioneer WARNING! Continuous exposure to high noise levels can Eclipse Authorized Distributor or Service Center. cause hearing loss. Hearing protection is recommended CAUTION! When loading or unloading machine onto or off while the machine is in operation.
- Page 8 This machine is designed and manufactured for indoor use in burnishing wax coated hard floor surfaces. Amano Canadian Safety Requirements Pioneer Eclipse does not recommend use of this machine in any environment other than an indoor environment. A sign indicating "NO SMOKING" shall be This propane powered floor machine is designed and permanently displayed at the storage area.
- Page 9 Surface of Hand-Guided Machinery During and after operation, perform the recommended daily and hourly procedures outlined in the Maintenance Amano Pioneer Eclipse measures and rates the vibration Chart. at the machine-hand contact surface of hand-guided machines that are provided with handles in accordance Test for Operator-Ear Sound Pressure Level with European Machinery Directive (98/37/EC).
-
Page 10: Machine Preparation
Open engine cover. Machine Preparation Unpacking the Machine The machine is shipped boxed on a wooden pallet. To unpack machine: Cut and remove black bands holding the box to the pallet. Remove staples attaching the box to the platform at the bottom edge of the box. With two people, one at either end of the box, lift box straight up and off machine. -
Page 11: Filling The Lp Cylinder
Filling the LP Cylinder Installing the LP Cylinder ® The Revolution uses the 20lb (9.1 kg) capacity cylinder, Place the Safe-Fill cylinder on the cylinder platform at the which meets the D.O.T. 4E240 standards. These cylinders back of the machine. Connect the fuel hose coupling to are also listed by UL. -
Page 12: Machine Components
Controls and Instruments Service Hour Engine Meter Indicator Emergency Engine Stop Shutdown Switch Button Indicator Service Engine Indicator Service Engine Indicator The Revolution has an onboard ECU that monitors and controls the engine’s fuel system. If a problem occurs, the Service Engine Indicator alerts the operator with a series of blink codes. -
Page 13: Engine Ignition Switch
Engine Ignition Switch and every 100 hours thereafter. At these intervals the meter will flash “OIL” for service. The meter will begin flashing one hour before recommended service interval The Revolution features a key switch ignition. and continue until one hour past the recommended service Start: Turn the key all the way clockwise or START to interval. -
Page 14: Pad Change
Pad Change Fuses Close the valve on the propane cylinder, allow the The machine’s electrical circuit is protected by fuses, engine to stop and turn the machine OFF. which stop the flow of current in the event of a circuit Remove the propane tank. -
Page 15: How The Machine Works
How the Machine Works Installing the LP Cylinder The Revolution is a propane burnisher that has a pad ® Place the Safe-Fill cylinder on the cylinder platform at the driver that is belt driven via an electric clutch. The clutch back of the machine. -
Page 16: Starting The Machine
Starting the Machine Burnishing Complete your pre-operation check. Dust mop and scrub the floor to clean it. Turn propane cylinder service valve After the engine has been started and properly counter-clockwise to open. warmed, pull back on the bail throttle to increase Note: Always open the service valve slowly to allow engine speed and engage the clutch. -
Page 17: Troubleshooting
Troubleshooting ECU with Engine Monitor and Diagnostic Software The Revolution comes with an onboard ECU that continually monitors and controls the engine's fuel injection system. The engine may be diagnosed by two methods. The first is by the blink codes that are displayed by the Service Engine Indicator on the control panel. - Page 18 Engine Monitor and Diagnostic Software Display Explanation Operating Mode: Tells operational status of Engine Monitoring Software. Start Now: Click this buttion to start the Engine Monitor Software. Tachometer: This measures the real time engine speed. Oil Pressure: Displays if the Engine Oil Pressure is normal. Sensor: Displays the Oxygen Sensor’s voltage signal.
-
Page 19: Engine Fuel Injection Troubleshooting
Engine Fuel Injection Troubleshooting... -
Page 20: Machine Troubleshooting
Machine Troubleshooting... -
Page 21: Scheduled Maintenance Chart
Scheduled Maintenance... -
Page 22: Engine Maintenance
Maintenance After the engine cover has been removed, remove the two front engine air scoop retaining knobs. Engine Note: For all maintenance procedures requiring the engine cover to be removed, please perform the following. Push the machine to a level surface, turn off the LP cylinder, and remove it. -
Page 23: Oil Level Inspection
Oil Level Inspection Push machine to level surface. Turn off LP cylinder and remove it. Open the engine cover. Clean area around the oil gauge (A) before removing it. Remove the oil gauge and wipe it with a clean cloth. Oil Drain Hose Place a suitable container under the end of the oil drain hose. -
Page 24: Oil Filter Replacement
Apply a thin coat of new oil or grease to the oil filter seal (A). Install the new filter (Amano Pioneer Eclipse part # KA920652078) by turning it clockwise. Turn the filter until the seal contacts the mounting surface (B) of the engine. -
Page 25: Air Filter Inspection And Replacement
If primary filter cannot be cleaned, is bent, or damaged, it must be replaced (Amano Pioneer Eclipse part # KA110137020). If secondary filter is dirty, do not attempt to clean it. Replace it with a new filter (Amano Pioneer Eclipse part # KA110137019). -
Page 26: Inspect Radiator And Hoses
Inspect Radiator and Hoses Check and adjust valve clearance. Re-torque heads: Push machine to level surface. Turn off LP cylinder and remove it. Refer to Kawasaki’s FD731V service manual. Remove the engine cover. Remove the engine air scoop. Clean and lap valve-seating surface: Check the radiator core. -
Page 27: Machine Maintenance
Maintenance Inspect the pad holder for cracks or damage. If the pad holder does not have any damage proceed to step 9. Machine WARNING! A damaged pad holder rotating at a high rate of speed may be an extreme hazard if it should come Clean Dust Container Filter apart. -
Page 28: Replace Drive Belt
The battery supplied with this machine is a sealed, absorbed glass mat (AGM), maintenance free type. It never needs servicing. When battery replacement is necessary, use Amano Pioneer Eclipse part #: MP120800. Push machine to level surface. Turn off LP cylinder and remove it. -
Page 29: Body Maintenance
Repacking the Machine PROPOSITION 65 WARNING Battery posts, terminals, and related Refer to Unpacking and repack the machine using original accessories contain lead and lead packing materials and container. compounds, chemicals known to the State of California to cause cancer and reproductive Transporting the Machine harm. -
Page 30: Machine Specifications
Machine Specifications Productivity Coolant: Permanent type of antifreeze for Burnishing Rate: aluminum engine. Mixed 50%. 28”: 34,000 ft /hr (3,159 m /hr) 24”: 28,000 ft /hr (2,601 m /hr) Coolant Capacity: 2.9 U.S. qt. (2.7 L) Engine Spark Plug Part #: KA920702112 Engine: Kawasaki FD731V, 675 cc, water- Spark Plug Gap: 0.025 in (0.635 mm) cooled. -
Page 31: Machine Specifications
Machine Specifications Deck Drive Drive: Electric clutch with B-Section Belt. Clutch: MP220000 Drive Belt: 28”: MP273000 24”: MP041000 Dust Container Filter: MP095100 Recommended Pads: 24” Blue Blend: PD006024 28” Blue Blend: PD006028 24” White Lightning: PD010024 28” White Lightning: PD010028 24”... -
Page 32: Wiring Schematic
Wiring Schematic 012809... -
Page 33: Wiring Schematic
Wiring Schematic Continued Exploded Views and Replacement Parts We recommend Amano Pioneer Eclipse quality parts, available through your Amano Pioneer Eclipse Distributor or direct from the factory. When you order parts, you need to have your machines serial number. This is the number that you... -
Page 34: Electrical Connections
Electrical Connections 012809... -
Page 35: Electrical Connections
Electrical Connections Continued 050808 Ref. Part # Description Qty. Ref. Part # Description Qty. RV023000 HARNESS, WIRING, REVOLUTION MP273800 WIRE, GROUND, METER, HOUR MP273300 HARNESS, WIRING, SWITCH, KEY MP273900 HARNESS, WIRING, SWITCH, CLUTCH MP273400 HARNESS, WIRING, METER, HOUR 1 SS2570 FUSE, 20 AMP, ATO MP273500 WIRE, E-STOP, RELAY... -
Page 36: Bulkhead Assembly
Bulkhead Assembly 083107 RF009600 Ref. Part # Description Qty. Ref. Part # Description Qty. RV016400 FRAME, REVOLUTION, ASM. 14 RV019600 HANDLE, REVOLUTION, ASM. MX1075 WASHER, LOCK, 3/8” 15 RV019900 BULKHEAD, TANK, LP, WELDMENT 1 NB6110 WASHER, LOCK, 1/4” 16 NB6501 INSERT, 1/4-20, COMPRESSION TYPE NB3350... -
Page 37: Frame Assembly
Frame 083007 Ref. Part # Description Qty. Ref. Part # Description Qty. RV016500 FRAME, REVOLUTION, WELDMENT 1 NB049200 SCREW, BH, 10-24 X 5/8”, SS MP027500 CASTER, 3.5”, SWIVEL, PLATE 10 NB9510 NUT, SPIN LOCK, 10-24 MOUNT 11 RV018000 BLOCK, MOUNTING, FRAME, RS NB6545 SCREW, CAP, HH, 5/16”-18 X 1”... -
Page 38: Handle Assembly
Handle Assembly 030807 Ref. Part # Description Qty. Ref. Part # Description Qty. RV015000 HANDLE, REVOLUTION, SLOTTED 1 NB9645 WASHER, FLAT, #10 MP272100 GRIP, FOAM, 1 1/8” I.D. X 24” NB4382 SCREW, DRILL KWIK, 8 X 1/2” RV011200 BAIL, ASM. NB028300 BUSHING, CABLE, BAIL NB012200... -
Page 39: Control Panel
Control Panel 030807 Ref. Part # Description Qty. RV020801 PANEL, DASH, CONTROL, FORMED 1 RV020900 DECAL, PANEL, DASH MP200100 LIGHT, RED, EXTERNAL RESISTOR 2 MP199000 KEYSWITCH, BURNISHER, RIDE-ON MP151700 SWITCH, STOP, EMERGENCY MP139800 EDGING, WEAR, SKIRT, STEEL 032907... -
Page 40: Bottom Assembly
Bottom Assembly 030308... -
Page 41: Bottom Assembly
Bottom Assembly Ref. Part # Description Qty. RV016400 FRAME, REVOLUTION, ASM. Ref. Part # Description Qty. MP318600 SPINDLE, REVOLUTION, THREADED, 17 NB5700 WASHER, .755 X 1.005 X .060, SS ASM. 18A MP329300 PULLEY, 8.00” w/ 1” BORE MX1105 WASHER, LOCK, 1/2” 18B MP267100 PULLEY, 9.75”, w/ 1”... -
Page 42: Deck Assembly
Deck Assembly 030308... -
Page 43: Deck Assembly
Deck Assembly Continued 24” PADHOLDER ASSEMBLY 28” PADHOLDER ASSEMBLY Ref. Part # Description Qty. Ref. Part # Description Qty. MP047500 PADHOLDER, 24”, COMPLETE ASM. 1 MP032500 PADHOLDER, 28”, COMPLETE ASM. 1 1.1 MP196300 RING, RELIEF, STRESS, LARGE, 1.1 MP196300 RING, RELIEF, STRESS, LARGE, PADHOLDER PADHOLDER 1.2 NB3275... -
Page 44: Engine Assembly
Engine Assembly 083107... -
Page 45: Engine Assembly
Engine Assembly Continued Ref. Part # Description Qty. NB4791 SCREW, CAP, 3/8 X 2” MX1075 WASHER, LOCK, 3/8” RV019100 ENGINE, KAWASAKI, FD731V, REV., ASM. MP250300 CLUTCH, RXL40, ASM. NB9745 SCREW, CAP, 5/16”-18 X 3/4” NB6111 WASHER, LOCK, 5/16” NB3350 WASHER, FLAT, 1/4” MP271800 MUFFLER, EXHAUST, ENGINE, FD731V... -
Page 46: Engine
Engine 050808... -
Page 47: Engine
Engine Continued Ref. Part # Description Qty. MP195100 ENGINE, KAWASAKI, 26HP, FD731V 1 MP243800 CARBURETOR, FD731V, ASM. NB007000 NUT, LOCK, NYLON, 4-40 NB007100 WASHER, FLAT, #6 NB012300 WASHER, LINKAGE, .275 HOLE & .070 HOLE MP271601 BRACKET, SWITCH, CLUTCH, FORMED MP271701 PLATE, ENGAGEMENT, SWITCH, PAINTED NB9625... -
Page 48: Final Assembly
Final Assembly 012909... -
Page 49: Final Assembly
Final Assembly Continued Ref. Part # Description Qty. MX1075 WASHER, LOCK, 3/8” RV018100 COVER, BELT, REVOLUTION, ASM. 1 NB9745 SCREW, CAP, 5/16”-18 X 3/4” NB6111 WASHER, LOCK, 5/16” NB6530 SCREW, CAP, HH, 1/4”-20 X 1” NB6110 WASHER, LOCK, 1/4” RV018300 GRILL, EXHAUST, REVOLUTION, WELDMENT MP271000... -
Page 50: Engine Cover Assembly
Engine Cover Assembly 083007... -
Page 51: Engine Cover Assembly
Qty. RV023900 COVER, ENGINE, NXG, ASM. RV016300 COVER, ENGINE, REVOLUTION RV021400 DECAL, REVOLUTION, 16” MP023600 DECAL, PIONEER ECLIPSE RV022000 BRACKET, PIN, PIVOT, HINGE, ASM. 1 NB6110 WASHER, LOCK, 1/4” NB6530 SCREW, CAP, HH, 1/4”-20 X 1” RV024400 SUPPORT, COVER, ENG., RS, WELD. -
Page 52: Fuel Injection Assembly
Fuel Injection Assembly 050808 Ref. Part # Description Qty. Ref. Part # Description Qty. MP320701 BRACKET, MOUNTING, REGULATOR, MP306000 VALVE, FILLER, AIR TANK FORMED MP245600 REGULATOR, FUEL INJECTION NB6501 INSERT, 1/4”-20, COMPRESSION 10 NB9730 WASHER, STAR #8 TYPE 11 NB6540 SCREW, BH, 8-32 X 1/2 MP318900 INJECTOR, FUEL, PROPANE... -
Page 53: Dust Container Assembly
Dust Container Assembly 030807 Ref. Part # Description Qty. Ref. Part # Description Qty. RV023800 CONTAINER, DUST COLLECTION, RV021201 RETAINER, FILTER, FORMED NXG, TRIMMED MP272200 SPACER, 3/8” O.D. X 1/4” I.D. X RV015600 INSERT, FRAME, FILTER, 1/2” L REVOLUTION MP095100 FILTER, DUST COLLECTION, ASM. -
Page 55: Warranty
Parts affected by misuse, neglect, abuse, or expenses for service calls or travel. For the distributor in improper maintenance are not warranted. your area, call Amano Pioneer Eclipse Customer Service Department at 1-800-367-3550 or 1-336-372-8080. If you EXCEPTIONS: are dissatisfied with the service that you receive, call or... - Page 56 © 2007 Amano Pioneer Eclipse Corporation P.O. Box 909 Sparta, NC 28675 1-336-372-8080 1-800-367-3550 www.pioneer-eclipse.com Article #: Serial #: DOM: Built in NC, USA Machinery Directive 98/37/EC Restriction of Hazardous Substances Directive 2002/95/EC...
