Comtech EF Data MBT-4000B Installation And Operation Manual page 59

Multi-Band Transceiver System
Remote Command
Command
Valid on
Parameter (Instruction
MBT,
Type Code and
BDC, or
qualifier)
BUC
Retrieve N/A All
Configuration
Status
Arguments for Description of arguments
Command or (Note that all arguments are ASCII numeric codes, that is,
Response to
Query between 48 and 57)
65 bytes (MBT- Query only.
4000B) Used to Query the configuration status of the unit
98 bytes
(BDC), Example for MBT-4000B base:
76 bytes (BUC) <0001/RCS?{cr}
alphanumeric >0001/RCS={cr}
BF1=X {cr}
BF2=X {cr}
BT1=DN{cr}
BT2=UP{cr}
RED=0{cr}
RAM=00{cr}
MBT=N, A, or B
EXT=0{cr}{lf}
Example for BDC or BUC:
<0001A1/RCS?{cr}
>0001A1/RCS={cr}
FLO=06300{cr}
ATT=01.00{cr}
MUT=1{cr}
SLP=0.3{cr}
LCS=0{cr}
LCW=99{cr}
LFL=1{cr}
REF=XXXX{cr} (reserved for future use)
XRE=X{cr} (reserved for future use)
AFR=0{cr}{lf}
Note: for BUC, LCS, LCW, & LFL will not be shown.
Revision 0
MN/MBT4000B.IOM
ASCII codes
A-23
Query
Response to
(Instruction
Command
Code and
(target to controller)
qualifier)
N/A RCS?
Response to
query
(target to
controller)
RCS=x....x
(see
description for
details of
arguments)
