Multi-Band Transceiver System
Installation
2.2.4 A
C
UX
OMM
Notes:
1. Input from external amplifier.
2. Normally, an Input, when programmed as an output, this pin indicates
Online/Offline status of Unit 1.
1 (J9) P
C
IN
ONNECTIONS

Table 2-5. Aux Comm 1 (J9) Pin Connections

Pin
A
AUX Rx + A
B
AUX Rx – A
C
AUX Tx + A
D
AUX Tx – A
E
+12.6V LNA A
F
IO1 A/Fault see Note 1
G
IO1 B see Note 2
H
GND
Mating Connectors:
Cannon MS3116J12-8P
CN/MS3116J12-8P
AUX COMM1 (J9)
2-4
Revision 0
MN/MBT4000B.IOM
