Multi-Band Transceiver System
Remote Command
Command
Valid on
Parameter (Instruction
MBT,
Type Code and
BDC, or
qualifier)
BUC
Concise N/A All
Configuration
Status
Arguments for
Description of arguments
Command or
(Note that all arguments are ASCII numeric codes, that is,
Response to
ASCII codes between 48 and 57)
Query
48 bytes (BDC) Query only. Returns the summarized version of RCS.
41 bytes (BUC) Example for MBT-04000 base unit:
32 bytes (MBT)
<0001/CCS?{cr}
alphanumeric >0001/CCS=aa,bb,cc,dd,e,ff,g,h{cr}{lf}
Where:
aa=Frequency band for Unit 1 BXC ('C", 'X", 'Ka', 'Ku', or 'NA')
bb=NA
cc=Direction for Unit 1 BXC ('DN'=BDC, 'UP'=BUC, 'NA'=None)
dd=NA
e=Redundancy mode (0, 1, or 2)
ff=Automatic mode
g=Redundancy loop cable address
N=No Cable
A=MBT-A
B=MBT-B
h=External reference lock (1=locked, 0=Not locked)
Example BDC or BUC:
<0001A1/CCS?{cr}{lf}
>0001A1/CCS=aaaaa,bb.bb,c,d.d,e,ff,g,hhhh
,i,j,{CR}{lf}
Where:
aaaaa=Frequency in MHz
bb.bb=Attenuation in dB
c=mute state, 0=unmated, 1=muted
d.d=slope adjust
e=LNA current source (BDC only, BUC=X)
ff=LNA current window (BDC only, BUC=XX)
g=LNA fault logic (BDC only, BUC=X)
hhhh=XXXX (reserved for future use)
i=X (reserved for future use)
j=Fault recovery, 0=Manual, 1=Auto
Revision 0
MN/MBT4000B.IOM
A-12
Response to Query Response to
Command (Instruction
(target to Code and
controller) qualifier) controller)
N/A CCS? CCS=x....x
description for
arguments)
query
(target to
(see
details of
