Comtech EF Data MBT-4000B Installation And Operation Manual page 51

Multi-Band Transceiver System
Remote Command
Command
Valid on
Parameter (Instruction
MBT,
Type Code and
BDC, or
qualifier)
BUC
Concise N/A MBT
Utility Status
Set RTC
DAT=mmddyy All
(Real-Time-
Clock) Date
Enable Aux EAM=nm MBT
Com
Fault Input
Monitoring
Arguments for Description of arguments
Command or (Note that all arguments are ASCII numeric codes, that is,
Response to
Query
21 bytes Query only.
alphanumeric Used to query the utility status of the MBT-4000 Base Unit,
response is comma delimited.
Where:
aaaa=Physical Address
bbbb=Remote Baud Rate
Example:
<0001/CUS?
>0001/CUS=aaaa,bbbb{cr}{lf}
6 bytes, Command or Query.
numeric A command in the form mmddyy
where;
dd = day of the month, between 01 and 31
mm = month of the year, between 01 and 12
yy = year, between 00 and 96 (2000 to 2096)
Example: DAT=042503 would be April 24, 2003.
n=1 AUX Command or Query.
COMM1 EAM controls monitoring of external fault logic inputs to Aux Comm
connectors (J9 pin F). If enabled and external fault input is at Logic
m=0 1 ( > 2.6 vdc) a fault will be reported. This fault is reported has the
(disabled), 1 LNA I1 or LNA I2 status in the RAS? Query.
(monitoring
enabled) Note: The inputs may be driven by a contact closure relay. They
have an internal pull-up resistor (4.7k) to +5 vdc.
Example: EAM=11
Revision 0
MN/MBT4000B.IOM
ASCII codes
between 48 and 57)
A-15
Response to Query
Command (Instruction
(target to Code and
controller) qualifier)
N/A CUS?
DAT= (message DAT?
ok)
DAT? (received
ok, but invalid
arguments found)
DAT* (message
ok, but not
permitted in
current mode)
EAM=(message EAM?n
ok)
EAM?(received
ok, but invalid
arguments found)
Response to
query
(target to
controller)
CUS=x...x
(see
description for
details of
arguments)
DAT=mmddyy
(same format
as command
arguments)
EAM=nm
(same format
as command
arguments)
