2.1 U
NPACKING AND
Inspect shipping container for damage. If shipping containers are damaged, keep them
until contents of shipment have been carefully inspected and checked for normal
operation.
Remove the packing list from the outside of the shipping carton. Open the carton and
remove the contents, checking the contents against the packing list. Verify completeness
of the shipment and that the unit functions correctly. If damage is evident, contact the
carrier and Comtech EF Data immediately and submit a damage report. If the unit needs
to be returned to Comtech EF Data, use the original shipping container.
2.2 I
NSTALLATION AND
The Common Module of the MBT-4000B may be located near or on the antenna. The
band-specific BUC is latched into place on top of the Common Module (M&C, Power
Supply, Reference). Cables to the antenna and IDU complete the installation.

Chapter 2. Installation

I
NSPECTION
O
PERATION

Table 2-1. PWR IN (J1) Pin Connections

Pin
PWR IN (J1)
A
LINE
B
NEUTRAL
C
GND
Mating Connectors:
ITT Cannon KPT06B-12-3S
CEFD PN CN/MS-STPG03F02
2- 1
