Comtech EF Data MBT-4000B Installation And Operation Manual page 50

Multi-Band Transceiver System
Remote Command
Command
Valid on
Parameter (Instruction
MBT,
Type Code and
BDC, or
qualifier)
BUC
Concise N/A All
Maintenance
Status
Arguments for Description of arguments
Command or (Note that all arguments are ASCII numeric codes, that is,
Response to
Query
40 bytes Query only.
alphanumeric Used to query the maintenance status of the unit in concise format.
Response is comma delimited as follows:
Example:
<0001/CMS?{cr}
>0001/CMS=aaa.a,bbb.b,ccc.c,ddd.d,eee.e,fff.f,
ggg.g,h,I,j,k{cr} {lf}
All:
aaa.a=+15V power supply
bbb.b=+7.5V power supply
ccc.=+5V power supply
MBT-4000B Base Unit:
ddd.d=+28V power supply
eee.e=Ref oscillator tuning voltage
fff.f=LNA current in mA for LNA A (AUX COMM1)
ggg.g= LNB current in mA for the bias tee
h=local RF switch position (A, B, or N)
i=Local IF switch position (A, B, or N)
j=Remote RF switch position (A or B)
k=Remote IF switch position (A or B)
Note:
1. It is not possible to detect the absence of a remote switch.
2. N= Not present.
BDC:
ddd.d=XXX.X (reserved for future use)
eee.e=Synthesizer tuning voltage
fff.f=LNA current in mA.
ggg.g= Unit temperature in °C.
h – k= Not present
BUC:
ddd.d=XXX.X (reserved for future use)
eee.e=Synthesizer tuning voltage
fff.f=RF output power in dBm (reserved)
ggg.g=Unit temperature in °C
h – k= Not present
MN/MBT4000B.IOM
ASCII codes between
48 and 57)
A-14
Revision 0
Response to Query
Command (Instruction
(target to Code and
controller) qualifier)
N/A CMS?
Response to
query
(target to
controller)
CMS=...
(see description
for details of
arguments)
