Comtech EF Data MBT-4000B Installation And Operation Manual page 58

Multi-Band Transceiver System
Remote Command
Command
Valid on
Parameter (Instruction
MBT,
Type Code and
BDC, or
qualifier)
BUC
Retrieve N/A All
Alarm Status
Arguments for Description of arguments
Command or (Note that all arguments are ASCII numeric codes, that is,
Response to
Query between 48 and 57)
92 bytes MBT- Query only.
4000B Used to Query the Alarm status of the unit
64 bytes
(BUC), Example for MBT-4000B base:
74 bytes <0001/RAS?{cr}
(BDC), >0001/RAS={cr}
alphanumeric 15VT1=OK{cr}
7V5T1=OK{cr}
5VLT1=OK{cr}
28VT1=OK{cr}
REFLD=OK{cr}
IICST=OK{cr}
LNAC1=OK{cr}
LNAC2=OK{cr}
LNAW1=OK{cr}
LNAW2=OK{cr}
LNAI1=OK{cr}
LNAI2=OK{cr}{lf}
Example for BDC or BUC:
<0001A1/RAS?{cr}
>0001A1/RAS={cr}
15VLT=OK{cr}
7V5LT=OK{cr}
5VOLT=OK{cr}
REFLD=XX {cr} (reserved for future use)
SYNLD=OK{cr}
HSTMP=OK{cr}
LNACR=OK{cr}{lf}
Notes:
1. LNACR will only appear for BDC.
2. FT reported if MAX current exceeded.
3. FT reported if LCW window current exceeded.
4. FT reported if EAM = 11 & Pin F of J9 High.
5. FT reported if EAM = 21 & Pin F of J8 High, not
applicable to MBT-4000B.
Revision 0
MN/MBT4000B.IOM
ASCII codes
(Note 2)
(Note 2)
(Note 3)
(Note 3)
(Note 4)
(Note 5)
A-22
Query
Response to
(Instruction
Command
Code and
(target to controller)
qualifier)
N/A RAS?
Response to
query
(target to
controller)
RAS=x....x
(see
description for
details of
arguments)
