Multi-Band Transceiver System
Installation
2.2.5 RF S
WITCH
(J10) P C
IN ONNECTIONS

Table 2-6. RF Switch (J10) Pin Connections

Pin
A POS 1 RF
B GND
C POS 2 RF
D POS 1 IND RF
E GND
F POS 2 IND RF
Mating Connectors:
MS3116J10-6P
CN/MS3116J10-6P
RF SWITCH (J10)
2-5
Revision 0
MN/MBT4000B.IOM
