2.2.1 COMM (J2) P C
IN ONNECTIONS

Table 2-2. COMM (J2) Pin Connections

Pin
A RS 485 Rx+
B RS 485 Rx-
C RS 485 Tx+
D RS 485 Tx-
E RS 232 RD
F NC
G RS 232 TD
H NC
J NC
K SUM FLT COMM
L SUM FLT NO
M SUM FLT NC
N NC
P NC
R NC
S NC
T GND
U GND
V NC
Mating Connectors:
Cannon MS3116J14-19P
CEFD CN/MS3116J14-19P
