  • Page 1 UPER ® SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Revision 1.0b...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 8027R-TRF+/7RFT+ Installation and maintainance should be performed by experienced technicians only. The SuperServer 8027R-TRF+/7RFT+ is a high-end server based on the SC828TQ-R1K43LPB 2U rackmount chassis and the X9QRi-F+/X9QR7-TF+ quad processor serverboard.
  • Page 4 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC828TQ-R1K43LPB server chassis. You should follow the procedures given in this chapter when installing, removing or reconfi guring SAS/SATA or peripheral drives and when replacing system power supply units and cooling fans.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Serial ATA ....................... 1-2 SAS ........................ 1-2 Onboard Controllers/Ports ................1-3 Graphics Controller ..................1-3 Other Features ....................1-3 Server Chassis Features ................
  • Page 7 Table of Contents Rack Mounting Instructions ................2-4 Identifying the Sections of the Rack Rails ............2-4 Locking Tabs ....................2-5 Releasing the Inner Rail ................. 2-6 Installing The Inner Rails on the Chassis ............2-7 Installing the Outer Rails on the Rack ............2-8 Standard Chassis Installation .................
  • Page 8 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Chapter 5 Advanced Serverboard Setup Handling the Serverboard ................5-1 Precautions ..................... 5-1 Unpacking ....................... 5-1 Connecting Cables ..................5-2 Connecting Data Cables ................. 5-2 Connecting Power Cables ................5-2 Connecting the Control Panel ................. 5-2 I/O Ports ......................
  • Page 9 Table of Contents Power Supply ....................6-10 Removing the Power Supply................. 6-10 Installing the Power Supply ................6-12 Chapter 7 BIOS Introduction ...................... 7-1 Starting the Setup Utility ................. 7-1 Main Menu ...................... 7-1 Advanced Settings Menu ................7-2 Event Logs ....................7-24 IPMI .......................
  • Page 10 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Notes...

  • Page 11: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction Overview The SuperServer 8027R-TRF+/7RFT+ is a high-end server comprised of two main subsystems: the SC828TQ-R1K43LPB 2U server chassis and the X9QRi-F+/X9QR7-TF+ dual processor serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 12: Serverboard Features

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Serverboard Features At the heart of the SuperServer 8027R-TRF+/7RFT+ lies the X9QRi-F+/X9QR7-TF+, ® a dual processor serverboard based on the Intel C602 chipset. Below are the main features of the X9QRi-F+/X9QR7-TF+. (See Figure 1-1 for a block diagram of the chipset).

  • Page 13: Onboard Controllers/Ports

    Chapter 1: Introduction Onboard Controllers/Ports The color-coded I/O ports on the X9QRi-F+/X9QR7-TF+ include one COM port, a VGA (monitor) port, fi ve USB 2.0 ports (four rear access I/O panel, 1x Type-A connection), two gigabit/10-gigabit Ethernet ports and one dedicated IPMI LAN port. Note 1: For more information on IPMI confi...

  • Page 14: Front Control Panel

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Front Control Panel The control panel on the SuperServer 8027R-TRF+/7RFT+ provides you with system monitoring and control. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included.

  • Page 15: System Block Diagram

    Chapter 1: Introduction Figure 1-1. Intel C602 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. 10Gbit/1G/1000BaseT RJ45 TX LAN Twinville DDR3-DMM DDR3-DMM DDR3-DMM DDR3-DMM DDR3-DMM DDR3-DMM 1066/1333/1600 1066/1333/1600 1066/1333/1600 1066/1333/1600 Dual 10GbE 1066/1333/1600 1066/1333/1600 10Gbit/1G/1000BaseT...

  • Page 16: Contacting Supermicro

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 17: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get your SuperServer 8027R-TRF+/7RFT+ up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled.

  • Page 18: Choosing A Setup Location

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for suffi cient airfl ow and ease in servicing. •...

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...

  • Page 20: Reliable Ground

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Reliable Ground A reliable ground must be maintained at all times. To ensure this, the rack itself should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (i.e. the use of power strips, etc.).

  • Page 21: Locking Tabs

    Chapter 2: Server Installation Figure 2-1: Identifying the Outer Rail, Middle Rail and Inner Rails (Left Rail Assembly Shown) Rail Assembly (Shown with Rails Outer Rail Retracted) Middle Rail Locking Tab Inner Rail This Side Faces Outward Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed and pushed fully into the rack.

  • Page 22: Releasing The Inner Rail

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Releasing the Inner Rail Releasing Inner Rail from the Outer Rails (Figure 2-2) 1. Identify the left and right outer rail assemblies as described on page 2-4. 2. Pull the inner rail out of the outer rail until it is fully extended as illustrated below.

  • Page 23: Installing The Inner Rails On The Chassis

    Chapter 2: Server Installation Installing The Inner Rails on the Chassis Installing the Inner Rails (Figures 2-3 and 2-4) 1. Confi rm that the left and right inner rails have been correctly identifi ed. 2. Place the inner rail fi rmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 24: Installing The Outer Rails On The Rack

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing the Outer Rails on the Rack Installing the Outer Rails (Figure 2-5) 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3.

  • Page 25: Standard Chassis Installation

    Chapter 2: Server Installation Standard Chassis Installation Installing the Chassis into a Rack (Figure 2-6) 1. Confi rm that the inner rails are properly installed on the chassis. 2. Confi rm that the outer rails are correctly installed on the rack. 3.

  • Page 26: Optional Quick Installation Method

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Optional Quick Installation Method The following quick installation method may be used to install the chassis onto a rack. Installing the Chassis into a Rack 1. Install the whole rail assembly onto the rack as described on page 5-7. 2.
  • Page 27 Chapter 2: Server Installation Notes 2-11...

  • Page 28: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel of the 8027R-TRF+/7RFT+ server as well as others on the drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi c components. There are also two buttons on the chassis control panel.

  • Page 29: Control Panel Leds

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Control Panel LEDs The control panel located on the front of the chassis has several LEDs (see Figure 3-1). These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 30: Nic1

    Chapter 3: System Interface NIC1 Indicates network activity on the LAN1 port when fl ashing. NIC2 Indicates network activity on the LAN2 port when fl ashing. On the SUPERSERVER 8027R-TRF+/7RFT+, this LED indicates hard drive and/ or DVD-ROM drive activity when fl ashing. Power Indicates power is being supplied to the system's power supply units.

  • Page 31: Drive Carrier Leds

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Drive Carrier LEDs Each drive carrier has two LEDs: SATA Drives • Green: When illuminated, the green LED on the SATA drive carrier indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.

  • Page 32: Chapter 4 Standardized Warning Statements For Ac Systems

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 33 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 34 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...

  • Page 35: Installation Instructions

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 36: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. 警告 此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电 流不大于250V,20A。 警告 此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電 流不大於250V,20A。...

  • Page 37: Power Disconnection Warning

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL ‫ﻓﻲ‬ ‫ﺍﻟﺘﻲ ﺗﻢ ﺗﺜﺒﻴﺘﻬﺎ‬ ‫ﻣﻦ ﺍﻟﺪﻭﺍﺋﺮﺍﻟﻘﺼﻴﺮﺓ‬ ‫ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﻳﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ﻫﺬﺍ ﺍﻟﻤﻨﺘﺞ‬ ‫ﺍﻟﻤﺒﻨﻰ‬ ‫ﺃﻛﺜﺮ ﻣﻦ‬ ‫ﻟﻴﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫ﺍﻟ‬ ‫ﺍﻟﺠﻬﺎﺯ‬ ‫ﺗﻘﻴﻴﻢ‬ ‫ﺃﻥ‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie.
  • Page 38 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 39: Equipment Installation

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi ziertem Personal gestattet werden. ¡Advertencia! Solamente el personal califi...

  • Page 40: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 41: Battery Handling

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬ ‫ﻓﻘﻂ‬...
  • Page 42 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 43: Redundant Power Supplies

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 44: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken. Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is...

  • Page 45: Comply With Local And National Electrical Codes

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬...

  • Page 46: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 47: Hot Swap Fan Warning

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 48 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 49: Power Cable And Ac Adapter

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Waarschuwing Het is mogelijk dat de ventilator nog draait tijdens het verwijderen van het ventilatorsamenstel uit het chassis. Houd uw vingers, schroevendraaiers en eventuele andere voorwerpen uit de buurt van de openingen in de ventilatorbehuizing. Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors.
  • Page 50 Chapter 4: Warning Statements for AC Systems ¡Advertencia! Al instalar el producto, utilice los cables de conexión previstos o designados, los cables y adaptadores de CA. La utilización de otros cables y adaptadores podría ocasionar un mal funcionamiento o un incendio. Aparatos Eléctricos y la Ley de Seguridad del Material prohíbe el uso de UL o CSA cables certifi...
  • Page 51 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Waarschuwing Bij het installeren van het product, gebruik de meegeleverde of aangewezen kabels, stroomkabels en adapters. Het gebruik van andere kabels en adapters kan leiden tot een storing of een brand. Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertifi...

  • Page 52: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X9QRi-F+/X9QR7-TF+ serverboard into the chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 53: Connecting Cables

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Connecting Cables Now that the serverboard is installed, the next step is to connect the cables to the board. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed to prevent them from blocking the fl...

  • Page 54: I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground 3.3 V FP PWRLED HDD LED ID_UID_SW/3/3V Stby NIC1 Link LED NIC1 Activity LED NIC2 Activity LED NIC2 Link LED Blue+ (OH/Fan Fail/ Red+ (Blue LED Cathode) PWR FaiL/UID LED) Power Fail LED 3.3V Reset...

  • Page 55: Installing The Processor And Heatsink

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing the Processor and Heatsink Caution: Avoid placing direct pressure to the top of the processor package. Always remove the power cord fi rst before adding, removing or changing any hardware components. Caution: The Quad MB (4 CPU socket) was recommended to install all the 4 CPU to make sure every function can work properly.
  • Page 56 Chapter 5: Advanced Serverboard Setup 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Press down on the load Pull the lever away lever labeled 'Close 1st' from the socket 3.
  • Page 57 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL 5. Use your thumb and index fi nger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6. Once they are aligned, carefully lower the CPU straight down into the socket. (Do not drop the CPU on the socket.
  • Page 58 Chapter 5: Advanced Serverboard Setup 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 8. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' fi...

  • Page 59: Installing A Passive Cpu Heatsink

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing a Passive CPU Heatsink Note: Make sure the heatsink is placed so that the fi ns of the heatsink are in the direction of the airfl ow in your system. 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied.

  • Page 60: Removing The Heatsink

    Chapter 5: Advanced Serverboard Setup Removing the Heatsink Caution: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket. 1.

  • Page 61: Installing Memory

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing Memory Caution: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X9QRi-F+/X9QR7-TF+ has thirty-two (32) single/dual/tri/quad channel 240- pin DIMM sockets that can support up to 1024 GB of Registered (RDIMM), Load Reduced (LRDIMM) ECC or Unbuffered (UDIMM) ECC/Non-ECC DDR3 1600/1333/1066/800 MHz speed SDRAM in a two-channel memory bus.

  • Page 62: Processor & Memory Module Population Confi Guration

    Chapter 5: Advanced Serverboard Setup Processor & Memory Module Population Confi guration For memory to work properly, follow the tables below for memory installation. Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU1 P1-A1 P1-A2 P1-B1 P1-B2 P1-C1 P1-C2 P1-D1 P1-D2...

  • Page 63: Populating Memory Modules

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Populating Memory Modules Intel E5-4600 Series Processor UDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated by Slot per DIMM & Per DIMM Channel (SPC) and DIMM Per Channel (DPC) Data Width 1 Slot Per 2 Slots Per Channel (See the Note below) Channel...

  • Page 64: Other Important Notes And Restrictions

    Chapter 5: Advanced Serverboard Setup Intel E5-4600 Series Processor LRDIMM Memory Support Ranks Per Memory Capacity Speed (MT/s) and Voltage Validated by Slot DIMM & Data Per DIMM per Channel (SPC) and DIMM Per Channel Width (DPC) 1 Slot Per Channel 2 Slots Per Channel (See the Note Below)

  • Page 65: Serverboard Details

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Serverboard Details Figure 5-4. X9QRi-F+/X9QR7-TF+ Layout USB0/1 COM1 LAN1 LAN2 USB2/3 LAN CTRL BMC CTRL IPMI_LAN X9QR7-TF+/X9QRi-F+ Rev. 1.02 UFBMC1 CPU4 CPU3 CPU1 CPU1 CLPD CPU1 CPU2 JPW5 CPU1 CPU1 LS2E1 JPW4 JPW3 JPW2 JPW1 JPI2C1 SAS CTRL FAN6 FAN5...
  • Page 66 Chapter 5: Advanced Serverboard Setup X9QRi-F+/X9QR7-TF+ Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPRST1 BMC Reset Off (Normal) JPS1 SAS Enable/Disable Pins 1-2 (Enabled) JPT1 TPM Enable/Disable Pins 1-2 (Enabled)

  • Page 67: Connector Defi Nitions

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Connector Defi nitions Main ATX Power Supply Connector ATX Power 24-pin Connector Pin Defi nitions A 2 4 - p i n m a i n p o w e r s u p p l y Pin# Defi...
  • Page 68 Chapter 5: Advanced Serverboard Setup Reset Button Reset Button Pin Defi nitions Pins 3 and 4 of JF1 attaches to the (JF1) reset button on the computer chassis. Pin# Defi nition See the table on the right for pin Reset defi...
  • Page 69 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Power On LED Power LED Pin Defi nitions (JF1) The Power On LED connector is Pin# Defi nition located on pins 15 and 16 of JF1 3.3V (use JLED for a 3-pin connector). This connection is used to provide LED Control indication of power being supplied to the system.
  • Page 70 Chapter 5: Advanced Serverboard Setup Power LED/Speaker PWR LED Connector On JD1 header, pins 1-3 are for a Pin Defi nitions power LED and pins 4-7 are for the Pin# Defi nition speaker. Pins 4-7 are available for Anode (+) connection to an external speaker.
  • Page 71 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL IPMB Header IPMB Header Pin Defi nitions A System Management Bus header for Pin# Defi nition IPMI 2.0 is located at JIPMB1. Connect Data the appropriate cable here to use the Ground IPMB I C connection on your system. Clock No Connection SGPIO...
  • Page 72 Chapter 5: Advanced Serverboard Setup Universal Serial Bus (USB) Backplane Accessible USB Connectors Four Universal Serial Bus ports Pin Defi nitions ( U S B 0 / 1 , U S B 2 / 3 ) a r e l o c a t e d USB 0/2 USB 1/3 Pin # Defi...
  • Page 73 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Unit Identifi er Switch UID Switch A Unit Identifier (UID) switch and Pin# Defi nition two LED indicators are provided on Ground the serverboard. The UID Switch is Ground located next to the LAN ports on the Button In I/O backplane.

  • Page 74: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the Jumper motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Setting pins to change the function of the connector.
  • Page 75 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL GLAN1/2 Enable/Disable GLAN1/2 Enable/Disable Jumper Settings Change the setting of jumper JPTG1 Jumper Setting Defi nition to enable or disable the LAN1/LAN2 Pins 1-2 Enabled Ethernets port on the serverboard. The default setting is enabled. See the Pins 2-3 Disabled table on the right for jumper settings.

  • Page 76: 5-10 Onboard Indicators

    Chapter 5: Advanced Serverboard Setup BMC Reset BMC Reset Jumper Settings Use jumper JPRST1 to reset the BMC Jumper Setting Defi nition settings on the motherboard. See the Closed BMC Reset table on the right for jumper settings. Open Normal (Default) 5-10 Onboard Indicators GLAN LEDs GLAN LED...
  • Page 77 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL BMC Heartbeat LED BMC Heartbeat LED Status A BMC Heartbeat LED is located Color/State Defi nition at DS1 on the motherboard. When Green: Blinking BMC: Normal DS1 is blinking, BMC is functioning normally. See the table at right for more information.

  • Page 78: 5-11 Sas/Sata Ports

    Chapter 5: Advanced Serverboard Setup 5-11 SAS/SATA Ports SATA Ports SATA Port Pin Defi nitions There are no jumpers to confi gure the (I-SATA0 ~ I-SATA5) onboard SATA ports. These ports are Pin # Defi nition supported by the Intel chipset. See Ground the table on the right for pin defi...

  • Page 79: 5-12 Installing Software

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO fi...
  • Page 80 SuperDoctor III, as the SuperDoctor III settings override the BIOS settings. To set the BIOS temperature threshold settings again, you would fi rst need to uninstall SuperDoctor III. Figure 5-6. Supero Doctor III Interface Display Screen (Health Information) 5-29...

  • Page 81: Superdoctor Iii

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Figure 5-7. Supero Doctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/software/ SuperDoctorIII.cfm. For Linux, we recommend that you use the SuperDoctor II application instead.

  • Page 82: 5-13 Serverboard Battery

    Chapter 5: Advanced Serverboard Setup 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-5). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 83 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Notes 5-32...

  • Page 84: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC828TQ-R1K43LPB chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered.

  • Page 85: Control Panel

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Figure 6-1. Front and Rear Chassis Views Control Panel Power Supplies (2) SATA Drives (6) Expansion Slots (6) COM1 Port USB Ports VGA Port IPMI LAN Ethernet Ports Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.
  • Page 86 Chapter 6: Advanced Chassis Setup 3. Press the two release tabs on the top of the cover. 4. Slide the cover back. 5. Lift the cover upwards Figure 6-2: Removing the Chassis Cover Figure 6-3: Lifting the Chassis Cover...

  • Page 87: Removing And Installing Chassis Fans

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Removing and Installing Chassis Fans The SC828 chassis comes equipped with three 6500 RPM fans for optimal cooling. In the unlikely event that a fan needs to be replaced, removing and installing chassis fans is a simple procedure. Removing a Chassis Fan (Figure 6-4) 1.
  • Page 88 Chapter 6: Advanced Chassis Setup Installing a Chassis Fan (Figure 6-5) 6. Slide the fan housing into the chassis fan mounting bracket. 7. Push down gently on the top of the fan until it clicks into place 8. Reconnect the fan wiring to the connectors. 9.

  • Page 89: Installing The Air Shroud

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing the Air Shroud The air shroud is used to channel the air fl ow from the system fans and direct it into critical areas of the chassis that require cooling. The SC828 chassis comes equipped with an optimized air shroud, which allows the direction of the airfl ow to be fi...

  • Page 90: Expansion Slot Setup

    Chapter 6: Advanced Chassis Setup Expansion Slot Setup The SC828 chassis includes four slots for expansion cards. Installing an Expansion Card (Figure 6-7) 1. Confi rm that each expansion card includes a standard L-bracket. 2. Disconnect the power supply, lay the chassis on a fl at surface and open the chassis cover.

  • Page 91: Removing The Hard Drive Tray And Installing A Hard Drive

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Removing the Hard Drive Tray and Installing a Hard Drive To install a hard disk drive into the chassis, it is necessary to remove the HDD carrier from the chassis. Removing a Hard Drive Carrier 1. Press the release tab on the front of each hard drive try to unlock the HDD carrier.
  • Page 92 Chapter 6: Advanced Chassis Setup Replacing a Hard Drive in the Hard Drive Carrier (Figure 6-9 & Figure 6-10) 1. Remove the two screws that attach to the both sides of the dummy HDD. 2. Slide out the dummy HDD as shown Figure 6-9: Removing the Dummy Hard Drive 3.

  • Page 93: Power Supply

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing a Hard Drive and Hard Drive Carrier into the Chassis (Figure 6-11) 1. Insert the hard drive and hard drive carrier into the hard drive carrier slot in the chassis. 2. Fold the HDD carrier's handle inward until it clicks into the locked position. Figure 6-11: Installing the Hard Drive and Carrier into the Chassis Caution: All of the drive carriers must remain in the drive bays to maintain proper cooling airfl...
  • Page 94 Chapter 6: Advanced Chassis Setup Figure 6-12: Releasing the Power Supply Release Button Handle 4. Gently pull the power supply forward and out of the chassis (Figure 6-13). Figure 6-13: Removing the Power Supply 6-11...

  • Page 95: Installing The Power Supply

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Installing the Power Supply Power Supply Installation 1. Unplug all power leading to the chassis. 2. Insert the power supply into its slot in the front of the chassis, gently pushing it back into the chassis until it clicks into position (Figure 6-14). 3.

  • Page 96: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the SuperServer 8027R-TRF+/7RFT+. The 16 MB SPI AMI BIOS® SM Flash BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.

  • Page 97: Advanced Settings Menu

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL System Time This item displays the system time in HH:MM:SS format (e.g. 15:32:52). Supermicro X9QR7-TF+ Displays the serverboard number. Version This item displays the SMC version of the BIOS ROM used in this system. Build Date This item displays the date that the BIOS ROM was built.
  • Page 98 Chapter 7: BIOS Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will immediately "capture" Interrupt 19 at bootup and allow the drives that are attached to these host adaptors to function as bootable disks.
  • Page 99 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL CPU Confi guration This submenu displays the information of the CPU as detected by the BIOS. It also allows the user to confi gure CPU settings.  Socket 1 CPU Information/Socket 2 CPU Information/ Socket 3 CPU Information/ Socket 4 CPU Information This submenu displays the following information regarding the CPUs installed in Socket 1/ Socket 2/ Socket 3/ Socket 4.
  • Page 100 Chapter 7: BIOS RTID (Record Types IDs) This feature displays the total number of Record Type IDs for local and remote pools. The options are Optimal and Alternate. Hyper-threading Select Enabled to support Intel Hyper-threading Technology to enhance CPU performance. The options are Enabled and Disabled. Active Processor Cores Set to Enabled to use a processor's second core and above.
  • Page 101 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL DCU Streamer Prefetcher (Available when supported by the CPU) Select Enabled to support Data Cache Unite (DCU) prefetch of L1 data to speed up data accessing and processing in the DCU to enhance CPU performance. The options are Disabled and Enabled. DCU IP Prefetcher Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch IP addresses to improve network connectivity and system...
  • Page 102 Chapter 7: BIOS P-STATE Coordination This feature selects the type of coordination for the P-State of the processor. P-State is a processor operational state that reduces the processor's voltage and frequency. This makes the processor more energy effi cient, resulting in further gains.

  • Page 103: North Bridge

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Long Duration Power Limit This item displays the power limit (in watts) set by the user during which long duration power is maintained. The default setting is 0. Factory Long Duration Maintained This item displays the period of time (in seconds) set by the manufacturer during which long duration power is maintained.
  • Page 104 Chapter 7: BIOS Data Direct I/O Select Enabled to enable Intel I/OAT (I/O Acceleration Technology), which signifi cantly reduces CPU overhead by leveraging CPU architectural improvements and freeing the system resource for other tasks. The options are Disabled and Enabled. DCA Support When set to Enabled, this feature uses Intel's DCA (Direct Cache Access) Technology to improve data transfer effi...
  • Page 105 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL CPU 1 PCIe Slot 3 Link Speed Select GEN1 to enable PCI-Exp Generation 1 support for Slot 3. Select GEN2 to enable PCI-Exp Generation 2 support for Slot 3. Select GEN3 to enable PCI-Exp Generation 3 support for Slot 3. The options are GEN1, GEN2, and GEN3.
  • Page 106 Chapter 7: BIOS DIMM Confi guration This section displays the following DIMM information. Current Memory Mode This item displays the current memory mode. Current Memory Speed This item displays the current memory speed. Mirroring This item displays if memory mirroring is supported by the motherboard. Memory mirroring creates a duplicate copy of the data stored in the memory to enhance data security.
  • Page 107 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL DDR Speed Use this feature to force a DDR3 memory module to run at a frequency other than what is specifi ed by the manufacturer. The options are Auto, Force DDR3-800, Force DDR3-1066, Force DDR3-1333, Force DDR3- 1600 and Force SPD.
  • Page 108 Chapter 7: BIOS Thermal Throttling Throttling improves reliability and reduces power consumption in the processor via automatic voltage control during processor idle states. The options are Disabled and CLTT (Closed Loop Thermal Throttling). South Bridge Confi guration This feature allows the user to confi gure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information.
  • Page 109 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL SATA Confi guration When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items. SATA Port0~SATA Port5 The AMI BIOS displays the status of each SATA port as detected by the BIOS. SATA Mode Use this feature to confi...
  • Page 110 Chapter 7: BIOS RAID Mode The following items are displayed when RAID Mode is selected: Port 0~5 Hot Plug Select Enabled to enable hot-plug support for the particular port. The options are Enabled and Disabled. PCIe/PCI/PnP Confi guration PCI ROM Priority Use this feature to select the Option ROM to boot the system when there are multiple Option ROMs available in the system.
  • Page 111 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL ASPM Support This feature allows the user to set the Active State Power Management (ASPM) level for a PCI-E device. Select Force L0s to force all PCI-E links to operate at L0s state. Select Auto to allow the system BIOS to automatically set the ASPM level for the system.
  • Page 112 Chapter 7: BIOS Super IO Confi guration Super IO Chip: This item displays the Super IO chip used in the motherboard. Serial Port 1 Confi guration Serial Port Select Enabled to enable a serial port specifi ed by the user. The options are Enabled and Disabled.

  • Page 113: Serial Port Console Redirection

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Device Mode Use this feature to select the desired mode for a serial port specifi ed. The options are Normal and High Speed. Serial Port 2 Attribute Use this feature to select the attribute for serial port 2. The options are SOL (Serial On LAN), and COM.
  • Page 114 Chapter 7: BIOS Data Bits Use this feature to set the data transmission size for Console Redirection. The options are 7 Bits and 8 Bits. Parity A parity bit can be sent along with regular data bits to detect data transmission errors.

  • Page 115: Console Redirection Settings

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SC0, ESCN, and VT400. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to confi...

  • Page 116: Acpi Settings

    Chapter 7: BIOS Flow Control This feature allows the user to set the fl ow control for Console Redirection to prevent data loss caused by buffer overfl ow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty.
  • Page 117 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Trusted Computing (Available when a TPM device is detected by the BIOS) Confi guration TPM Support Select Enabled on this item and enable the TPM jumper on the motherboard to enable TPM support to improve data integrity and network security. The options are Enabled and Disabled.
  • Page 118 Chapter 7: BIOS CPU: TXT (Trusted Execution Technology) Feature Chipset: TXT (Trusted Execution Technology) Feature Intel TXT (LT-SX) Confi guration This feature displays the following TXT confi guration setting. TXT (LT-SX) Support This item indicates if the Intel TXT support is enabled or disabled. The default setting is Disabled.

  • Page 119: Event Logs

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Event Logs Use this feature to confi gure Event Log settings.  Change SMBIOS Event Log Settings This feature allows the user to confi gure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 120: Ipmi

    Chapter 7: BIOS MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1. METW (Multiple Event Count Time Window) This item allows the user to decide how long (in minutes) should the multiple event counter wait before generating a new event log.
  • Page 121 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.

  • Page 122: Boot

    Chapter 7: BIOS The following items are assigned IP addresses automatically if DHCP is selected, or can be confi gured manually if Static is selected. Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253).

  • Page 123: Security

    SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Security This menu allows the user to confi gure the following security settings for the system. Administrator Password Use this feature to set the Administrator Password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.
  • Page 124 Chapter 7: BIOS Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup. When the dialog box appears, asking you if you want to load previous values, click Yes to load the values previous saved, or click No to keep the changes you've made so far.
  • Page 125 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Notes 7-30...

  • Page 126: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 127 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Notes...

  • Page 128: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors Quad Intel E5-4600 series series (Socket R-LGA 2011 type) processors Note: You must install at least two processors for full functions to be supported. Note: Please refer to our web site for a complete listing of supported processors. Chipset One Intel C602 chipset BIOS...
  • Page 129 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL Serverboard X9QRi-F+/X9QR7-TF+ (Proprietary form factor) Dimensions: (LxW) 16.79" x 16.40" (426.47 mm x 416.56 mm) Chassis SC828TQ-R1K43LPB (2U rackmount) Dimensions (both): (WxHxD) 17.2 x 3.5 x 27.75 in. (473 x 89 x 705 mm) Weight Gross (Bare Bone): 65.5 lbs. (29.8 kg.) System Cooling The SC828 chassis has three (3) 8-cm cooling fans (fan speed controlled by BIOS setting)
  • Page 130 Appendix B: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 131 SUPERSERVER 8027R-TRF+/7RFT+ USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

This manual is also suitable for:

Superserver 8027r-trf+Superserver 8027r-7rft+

Table of Contents
